| Ref | Part Number | Description |
|---|
| 1 |
532423469 |
WHEEL STEERING Price: $32.99 |
| 1 |
76-2760 |
HOSE ASSEMBLY Price: $259.75 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
76-2750 |
HOSE ASSEMBLY Price: $277.12 |
| 3 |
237-58 |
O-RING Price: $2.18 |
| 4 |
340-142 |
FITTING-ELBOW-90 This part replaces 95-1692. Price: $65.90 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 5 |
237-81 |
O-RING Price: $2.76 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
76-2770 |
HOSE ASM Price: $271.52 |
| 7 |
237-22 |
O-RING Price: $2.43 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
69-4320 |
FITTING-HYD, 90 DEG Price: $154.75 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
237-42 |
O-RING Price: $2.78 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
32128-21 |
NUT-HF Price: $0.39 |
| 11 |
94-4907 |
MOTOR-HYD Price: $1,685.80 |
| 12 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 13 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
69-6960 |
SPACER-IDLER Price: $22.57 |
| 15 |
140-5848 |
PULLEY-IDLER This part replaces 63-1540-03. Price: $62.48 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
325-7 |
SCREW-HH Price: $1.53 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 18 |
32108-103 |
SCREW-FH Price: $0.68 |
| 19 |
32128-20 |
NUT-HF Price: $0.99 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 21 |
32120-72 |
RING-SNAP Price: $2.09 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
256-188 |
BUSHING Price: $5.70 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 23 |
69-6610-01 |
ARM-IDLER Price: $84.61 |
| 24 |
325-8 |
SCREW-HH Price: $3.52 |
| 25 |
69-5430-03 |
PULLEY-IDLER, FLAT Price: $63.15 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 26 |
69-6970 |
SPACER-IDLER, FLAT Price: $13.54 |
| 27 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
92-3162 |
BUSHING Price: $2.78 |
| 29 |
3269-25 |
RIVET-POP Price: $0.27 |
| 30 |
69-6780 |
DISCONTINUED Price: Call Us |
| 31 |
69-6870 |
PLATE-MAGNET Price: $4.91 |
| 32 |
69-6260 |
MAGNET Price: $58.32 |
| 33 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 34 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 35 |
32128-23 |
NUT-HF Price: $1.51 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
76-1670-03 |
SPRING-EXTENSION Price: $24.92 |
| 37 |
3217-9 |
NUT-HH Price: $0.37 |
| 38 |
69-6550 |
TENSIONER WA Price: $72.13 |
| 39 |
95-0833 |
DECAL-BELT ROUTING,CENTER Price: $20.90 |
| 40 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 41 |
13-4969 |
FRONT DECK W/DECALS Price: $3,199.64 |
| 42 |
3233-27 |
SCREW-CARR Price: $2.17 |
| 43 |
98-0755-03 |
PLATE - TENSIONER,ASM Price: $74.44 |
| 44 |
77-2830 |
SPRING ROD Price: $85.37 |
| 45 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 48 |
86-7480 |
COMPRESSION SPRING Price: $35.91 |
| 50 |
23-1640 |
BUSHING-TAPERLOCK Price: $68.50 |
| 51 |
63-0660 |
GEARBOX PULLEY WA This part replaces 63-0660-03. Price: $80.31 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
69-6390-01 |
DISCONTINUED Price: Call Us |
| 53 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
69-6790 |
RH CENTER COVER Price: $140.29 |
| 56 |
95-0845 |
DECAL-HOC Price: $11.75 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 57 |
95-0817 |
DECAL-HOC Price: $10.90 |
| 58 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
3233-30 |
SCREW-CARR Price: $3.26 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 60 |
93-7824 |
DECAL-DANGER Price: $17.85 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 61 |
93-9324 |
IDLER PIVOT WA Price: $54.15 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 62 |
94-9820-01 |
BAR-GUARD, FRONT This part replaces 94-9820. Price: $53.35 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 63 |
94-9819-01 |
BAR-GUARD, FRONT CENTER This part replaces 94-9819. Price: $177.06 |
| 64 |
32144-11 |
SCREW-THD ROLL, HWH This part replaces 32104-31. Price: $6.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
98-3038 |
BUSHING-IDLER Price: $13.77 |
| 66 |
32149-1 |
NUT-KEPS Price: $5.59 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
322-6 |
SCREW-HH Price: $0.45 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 68 |
99-4444 |
FITTING-HYD Price: $146.74 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 69 |
99-4443 |
FITTING Price: $27.38 |
| 70 |
354-79 |
CAP-DUST Price: $7.81 |
