| Ref | Part Number | Description |
|---|
| 1 |
186093X428 |
Wheel, Steering Price: Call Us |
| 1 |
92-9200 |
COVER Price: $276.63 |
| 2 |
184706 |
Axle Asm., Front Price: Call Us |
| 2 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
60-2160 |
R-CLIP ASM Price: $8.47 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
403087 |
Spindle Asm., LH Price: Call Us |
| 5 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 5 |
403088 |
Spindle Asm., RH Price: Call Us |
| 6 |
3290-250 |
PIN-COTTER Price: $5.59 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
65-5890 |
CAP-END Price: $8.09 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 9 |
58-1650 |
ROD-SEAT Price: $110.80 |
| 10 |
82-9340 |
LEVEL SWITCH ASM Price: $201.99 |
| 11 |
65-5870 |
TUBE Price: $20.33 |
| 12 |
55-4660 |
ARMREST Price: $488.24 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
56-3850 |
SCREW Price: $3.37 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
115-2030 |
SEAT KIT - RM4000 This part replaces 77-4860. Price: $1,616.82 |
| 15 |
46-0670 |
SCREW-PPH Price: $1.89 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 16 |
408220 |
Shaft Steering Price: Call Us |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 19 |
60-5580 |
SWITCH-TEMPERATURE Price: $178.50 |
| 20 |
198375X428 |
Boot, Steering Price: Call Us |
| 20 |
323-7 |
SCREW-HH Price: $0.65 |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 22 |
32128-21 |
NUT-HF Price: $0.39 |
| 23 |
93-6686 |
DECAL-OIL, HYD Price: $7.01 |
| 24 |
60-0050 |
SPRING-TRAY, SEAT Price: $78.73 |
| 25 |
58-1640 |
PIN-PIVOT, SEAT Price: $59.26 |
| 26 |
186095X428 |
Insert, Wheel Steering Price: Call Us |
| 26 |
68-7850 |
STRIP-SEALING Price: $41.39 |
| 27 |
32128-20 |
NUT-HF Price: $0.99 |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 30 |
58-1580-03 |
FRAME-SEAT Price: $402.10 |
| 31 |
58-9830-03 |
PLATE-SEAT Price: $355.56 |
| 32 |
5-0652 |
SPACER This part replaces 26-4840. Price: $5.35 |
| 33 |
10040500 |
Washer Lock 5/16 Price: Call Us |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
2412-102 |
CLAMP-R Price: $6.85 |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 35 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 36 |
71-4040 |
HYD FILLER ASM Price: $69.67 |
| 37 |
58-6820 |
GASKET Price: $13.28 |
| 45 |
19113812 |
Washer 11/32 x 2-3/8 x 12 Ga. Price: Call Us |
| 50 |
73900600 |
Nut Lock Flg 3/8-16 unc Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x.060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex HS 3/8-16 unc x 2-1/4 Price: Call Us |
| 55 |
197636 |
Spacer Brace Axle Price: Call Us |
| 57 |
407465 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 70 |
196197 |
Bracket Deck Susp. Front Price: Call Us |
| 71 |
196075 |
Shaft Ext. Steering Price: Call Us |
