| Ref | Part Number | Description |
|---|
| 1 |
32128-19 |
NUT-HF Price: $0.99 |
| 1 |
71191008 |
SCREW.PNHD.10-24 Price: Call Us |
| 2 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 3 |
104164X |
TIE CABLE CRT Price: Call Us |
| 3 |
86-1820-01 |
BRACKET-PULLEY Price: $18.96 |
| 4 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 4 |
8206H |
GRIP T Price: Call Us |
| 5 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 5 |
4497H |
RETAINER M Price: Call Us |
| 6 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 6 |
81328 |
SHOULDER BOLT ST Price: Call Us |
| 7 |
109335X |
SHIFT HANDLE CRT Price: Call Us |
| 7 |
86-2400-01 |
LATCH-ARM Price: $109.47 |
| 8 |
109313X |
GROMMET CRT Price: Call Us |
| 8 |
325-5 |
SCREW-HH Price: $1.20 |
| 9 |
138400 |
ROD.SHIFT Price: Call Us |
| 9 |
86-1560 |
SPACER-CYLINDER, LIFT Price: $23.34 |
| 10 |
72110608 |
BOLT D Price: Call Us |
| 10 |
86-1490 |
END-ROD, LH THREAD Price: $84.31 |
| 11 |
109229X |
LOCK CRT Price: Call Us |
| 11 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 12 |
73930600 |
LOCKNUT Price: Call Us |
| 12 |
86-1570 |
ROD-THREADED Price: $55.04 |
| 13 |
19131611 |
WASHER CRT Price: Call Us |
| 13 |
3220-5 |
NUT-JAM This part replaces 3220-5-01. Price: $0.65 |
| 14 |
109228X |
LEVER LOCK CRT Price: Call Us |
| 14 |
86-1550 |
END-ROD, RH THREAD Price: $79.70 |
| 15 |
150256X505 |
SUB= 150256X431 Price: Call Us |
| 15 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 16 |
10040400 |
LOCKWASHER Price: Call Us |
| 16 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 17 |
73220400 |
SUB= 50675 Price: Call Us |
| 17 |
92-7766-01 |
BRACKET-PULLEY Price: $9.40 |
| 18 |
73731000 |
NUT Price: Call Us |
| 18 |
92-4033-01 |
TRAP-DOOR Price: $141.84 |
| 19 |
101251L |
CABLE-CLUTCH CRT Price: Call Us |
| 19 |
256-243 |
BEARING-FLANGE Price: $9.99 |
| 20 |
325-7 |
SCREW-HH Price: $1.53 |
| 20 |
9484R |
CONDIUT CLIP T Price: Call Us |
| 21 |
86777 |
SUB= 750097 Price: Call Us |
| 22 |
102604X |
GRIP BAR CRT Price: Call Us |
| 23 |
102744X |
SUB= 102744X431 Price: Call Us |
| 23 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 24 |
106-1057 |
KIT-CLUTCH BRACKETS This part replaces 86-2590. Price: $221.30 |
| 25 |
138305 |
CONTROL.THROTTLE Price: Call Us |
| 25 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 26 |
48-7081 |
GRIP-PLASTIC Price: $7.54 |
| 26 |
72140404 |
BOLT Price: Call Us |
| 27 |
86-2600-01 |
WASHER-GUIDE, BELT Price: $5.77 |
| 27 |
9266R |
SUB= 624A78 Price: Call Us |
| 28 |
138283 |
LOCK.HANDLE Price: Call Us |
| 28 |
3290-378 |
TIE-CABLE Price: $0.79 |
