| Ref | Part Number | Description |
|---|
| 1 |
16700-Z8A-004 |
PUMP ASSY., FUEL (MSDS) Price: $93.10 |
| 3 |
16882-ZL8-000 |
TUBE, DIAPHRAGM Price: $2.90 |
| 6 |
16952-Z8B-000 |
FILTER, FUEL Price: $27.68 |
| 7 |
17511-Z8A-801 |
TANK, FUEL Price: $26.92 |
| 10 |
17535-KE7-000 |
COLLAR, FUEL TANK SETTING Price: $4.58 |
| 11 |
17561-Z0J-000 |
STAY A, FUEL TANK Price: $7.34 |
| 12 |
17620-Z8B-800 |
CAP ASSY., FUEL TANK This part replaces 17620-Z0J-800. Price: $21.96 |
| 13 |
17701-Z8A-013 |
TUBE, FUEL TANK (FKM) Price: Call Us |
| 15 |
17702-Z8A-023 |
TUBE, FUEL This part replaces 17702-Z8A-013. Price: $11.14 |
| 20 |
90041-ZL8-000 |
BOLT, FUEL TANK STUD (H=30MM) Price: $5.08 |
| 21 |
90473-896-000 |
WASHER (6MM) Price: $2.42 |
| 23 |
93404-06025-00 |
BOLT-WASHER (6X25) Price: $1.38 |
| 24 |
93894-05014-00 |
SCREW-WASHER (5X14) Price: $1.10 |
| 25 |
94050-06000 |
SEE PART DETAILS - PRI; NUT, FLANGE (6MM) (Honda Code 0471623). Price: $0.82 |
| 31 |
17518-Z8A-800 |
COLLAR, TANK SET Price: $1.36 |
| 32 |
17532-Z8A-800 |
RUBBER A, TANK MOUNTING Price: $0.46 |
| 33 |
17533-Z8A-800 |
RUBBER B, TANK MOUNTING Price: $0.42 |
| 35 |
95002-40800-08 |
SEE PART DETAILS - PRI; CLIP, TUBE (D8) (Honda Code 0660811). Price: $2.82 |
| 36 |
95002-40850-08 |
CLIP, TUBE (D8.5) (Honda Code 0665240). Price: $3.18 |
| 37 |
95002-41000-08 |
CLAMP, TUBE (D10) Price: $2.94 |
