| Ref | Part Number | Description |
|---|
| 1 |
532414280 |
KNOB LEVER, BLACK This part replaces 532183334. Price: $6.99 |
| 1 |
93-7974-03 |
PLATE-BOX, BATTERY This part replaces 93-7974. Price: $87.76 |
| 2 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 2 |
934-0255 |
Tubeless Air Valve This part replaces 734-3068. Price: $3.83 |
| 3 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 3 |
587030801 |
CONTROL.ASM.DEFLEC.BLK.BOWDEN This part replaces 532178674. Price: $54.99 |
| 3 |
736-0242 |
Washer, .345 X .88 Belleville Price: $3.75 |
| 4 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 4 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 4 |
736-0231 |
Washer, .344 X 1.125 X .125 Price: $4.02 |
| 5 |
33005-00 |
NUT-HF Price: $0.68 |
| 5 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 5 |
736-3040 |
Washer, .406 X 1.92 X .06 Price: $5.52 |
| 6 |
108-3282 |
HOSE-FUEL This part replaces 92-7522. Price: $36.93 |
| 6 |
532178659 |
CONTROL ASSY, CHUTE ROTATER Price: $99.99 |
| 6 |
710-0627 |
Hex Bolt 5/16-24 x .75" This part replaces 710-3166. Price: $3.68 |
| 7 |
532443617 |
SUPPORT.WELDMENT.ROTATOR.BLACK This part replaces 532184089. Price: $24.99 |
| 7 |
66-8121 |
STANDPIPE Price: $23.18 |
| 7 |
931-3020 |
Hubcap This part replaces 731-3020. Price: $7.77 |
| 8 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 8 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 9 |
46-6560 |
BUSHING Price: $2.94 |
| 9 |
532184505 |
SPRING.DEFLECTOR.REM.CHUTE Price: $6.99 |
| 10 |
532179829 |
BOLT, SHOULDER Price: $4.99 |
| 10 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 11 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 11 |
532179246 |
WASHER, NYLON FRICTION Price: $3.99 |
| 12 |
304-46 |
DRAINCOCK Price: $7.55 |
| 12 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 13 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 13 |
596136401 |
Bolts This part replaces 872250505. Price: $2.99 |
| 14 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 14 |
63-8410 |
WASHER Price: $1.76 |
| 15 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 15 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532184112. Price: $17.99 |
| 16 |
105-7949 |
TANK-FUEL This part replaces 92-7422. Price: $768.96 |
| 16 |
590518207 |
DEFLECTOR ASSEMBLY RIVETED This part replaces 532184113. Price: $17.99 |
| 17 |
532420325 |
SEAL.DEFLECTOR This part replaces 532179145. Price: $5.99 |
| 17 |
62-7650 |
GASKET Price: $4.28 |
| 18 |
532128415 |
RIVET BLIND Price: $3.99 |
| 18 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 19 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 19 |
532183333 |
RP KNOB, SPEED CONTROL LEVER Price: $8.99 |
| 20 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 20 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 21 |
110-6184 |
HOSE-FUEL This part replaces 92-7521. Price: $49.59 |
| 21 |
532155415 |
WASHER.20X8.5 Price: $4.99 |
| 22 |
874041024 |
SCREW Price: $2.99 |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 23 |
532421249 |
CABLE.TRIGGER.CONTROL.ASM This part replaces 532192449. Price: $19.99 |
| 25 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 26 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198875. Price: $74.99 |
| 27 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 28 |
532180445 |
ROD, UPPER SPEED CONTROL Price: $34.99 |
| 29 |
532187716 |
ROD, LOWER SPEED CONTROL.SNOW Price: $17.99 |
| 30 |
532192710 |
CLAMP.ASM.CLEANOUT.TOOL.SNOW Price: $8.99 |
