| Ref | Part Number | Description |
|---|
| 1 |
629-3007 |
HARNESS-W/ELEC PTO Not Available Price: |
| 1 |
98-9575 |
WATER PUMP ASM Price: $347.70 |
| 2 |
532188220 |
GEARCASE.ASM.DRT.LH. Price: $129.99 |
| 2 |
710-0473 |
Screw, Truss Mach, #10-24 X .50 Lg Price: $3.90 |
| 2 |
98-9632 |
GASKET-PUMP, WATER Price: $7.25 |
| 3 |
532431022 |
GASKET.GEARCASE.CRT/DRT.TILLER Price: $17.99 |
| 3 |
712-3009 |
Screw, Pan Hd Cutting, #10-24 X .75 Lg Price: $5.99 |
| 3 |
98-9353 |
BOLT Price: $0.76 |
| 4 |
532005020 |
NEEDLE BRNG LT Price: $14.99 |
| 4 |
712-0161 |
Nut, Hex Lock, #10-24 Price: $4.02 |
| 4 |
98-9357 |
BOLT Price: $2.46 |
| 5 |
532001370 |
THRUST WASHER Price: $4.99 |
| 5 |
712-0207 |
SPEED NUT Not Available Price: |
| 5 |
98-9717 |
CLAMP Price: $8.41 |
| 6 |
586196201 |
PINION INPUT DRT TILLER This part replaces 532161520. Price: $39.99 |
| 6 |
721-3049 |
PROTECTIVE COVER Not Available This part replaces 721-3047. Price: |
| 6 |
98-9574 |
PIPE-WATER Price: $17.67 |
| 7 |
532161518 |
SHAFT.INPUT.D.9TEETH Price: $64.99 |
| 7 |
725-1655 |
HOLDER-INLINE FUSE Not Available Price: |
| 8 |
532004895 |
BEARING Price: $9.99 |
| 8 |
725-1656 |
FUSE 20 AMP. MINI. Not Available Price: |
| 9 |
532154467 |
WASHER, SEAL (2 2) Price: $3.99 |
| 9 |
925-1657A |
Switch This part replaces 725-1657. Price: $22.57 |
| 10 |
532100482 |
KIT.STEEL BALL(12 BALLS) This part replaces 532007392. Price: $4.99 |
| 11 |
532100371 |
SPRING-SHIFT CRT Price: $4.99 |
| 12 |
532106160 |
O-RING TI Price: $3.99 |
| 13 |
532142145 |
BRACKET ASM.SHIFT.CRT Price: $17.99 |
| 14 |
532008353 |
SHIFT FORK TI Price: $22.99 |
| 15 |
812000039 |
KLIP RING Price: $4.99 |
| 16 |
532161516 |
SHAFT.SHIFT.DRT Price: $7.99 |
| 18 |
532004358 |
WASHER Price: $3.99 |
| 19 |
812000040 |
KLIP RING Price: $4.99 |
| 20 |
532102114 |
GEAR ASSY CRT Price: $19.99 |
| 21 |
532102115 |
GEAR-REV IDLR CRT Price: $22.99 |
| 22 |
532006803 |
NEEDLE BEARING TI Price: $7.99 |
| 23 |
532161527 |
SHAFT.IDLER.REVERSE.CRT Price: $19.99 |
| 24 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 25 |
873610700 |
NUT.ASF.HEX.7/16 Price: $5.99 |
| 29 |
532102134 |
CHAIN CRT Price: $9.99 |
| 30 |
532150737 |
GROUND SHAFT ASS'Y Price: $54.99 |
| 32 |
532106388 |
SPACER TI Price: $5.99 |
| 33 |
532102121 |
SPRCKT 8 GEAR CRT Price: $37.99 |
| 34 |
532102112 |
SHAFT.SECONDARY.REDUCTION.CRT Price: $37.99 |
| 35 |
532102101 |
SCRW WHIZ LOK CRT Price: $3.99 |
| 36 |
532161524 |
GEAR & SPROCKET.ASM.WBEARIN Price: $139.99 |
| 37 |
585695501 |
NEEDLE BEARING This part replaces 532100413. Price: $7.99 |
| 38 |
532161524 |
GEAR & SPROCKET.ASM.WBEARIN This part replaces 532161525. Price: $139.99 |
| 39 |
532161526 |
GEAR.CLUSTER.DRT.TILLER Price: $37.99 |
| 40 |
532105346 |
GEAR TI Price: $39.99 |
| 41 |
532161523 |
SHAFT.REDUCTION.FIRST.DRT Price: $19.99 |
| 42 |
532004220 |
BRNG RACE T Price: $4.99 |
| 43 |
532106146 |
SPACER TI Price: $24.99 |
| 44 |
532155236 |
SEAL ASM, OIL Price: $5.99 |
| 49 |
532431485 |
SHAFT.ASM.TINE Price: $69.99 |
| 50 |
532106147 |
CHAIN.TILLER Price: $49.99 |
| 51 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 52 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 53 |
532165140 |
KIT.BEARING.TILLER. Price: $24.99 |
| 54 |
532161528 |
GEAR.ASM.DRT.TILLER Price: $49.99 |
| 55 |
580755701 |
DRAWN CUP ROLLER BEARING W/CAG This part replaces 532003400. Price: $7.99 |
| 57 |
532165889 |
SPACER.SPLIT Price: $6.99 |
| 58 |
532179520 |
BOLT SHOULDER 1/4-20 UNC X.875 Price: $3.99 |
| 60 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 61 |
532431015 |
SPACER.1.015X1.50X.650 Price: $5.99 |
