| Ref | Part Number | Description |
|---|
| 1 |
31442 |
Cylinder Assy. (Incl. Nos. 2,3,4 90) Price: Call Us |
| 1 |
HG70516 |
HOUSING KIT Price: Call Us |
| 2 |
26727 |
Pin-Dowel Price: Call Us |
| 2 |
HG70517 |
Kit, End Cap This part replaces HG70573. Price: Call Us |
| 3 |
27642 |
Plug-Drain, Oil (SQH 1/4-18) Price: Call Us |
| 3 |
HG50641 |
STRAIGHT HEADLESS PIN Price: Call Us |
| 4 |
29183 |
OIL SEAL Price: Call Us |
| 4 |
HG50969 |
HEX FLANGE BOLT, M8-1.25 X 60MM Price: Call Us |
| 5 |
31444 |
INTAKE VALVE (STANDARD) Price: Call Us |
| 5 |
HG54022 |
HOUSING, O'RING This part replaces HG51232. Price: Call Us |
| 6 |
31445 |
EXHAUST VALVE (STANDARD) Price: Call Us |
| 6 |
31483 |
EXHAUST VALVE (1/32" OVERSIZE) Price: Call Us |
| 6 |
HG2513027 |
CHARGE PUMP Price: Call Us |
| 7 |
26957 |
Cap, Upper valve spring Price: Call Us |
| 7 |
HG50273 |
GEROTOR ASSEMBLY Price: Call Us |
| 8 |
24772 |
Spring, Valve Price: Call Us |
| 8 |
HG9004101-1340 |
O-RING Price: Call Us |
| 9 |
21043 |
Fuel Line Carburetor Price: Call Us |
| 9 |
HG50095 |
SOCKET HEAD SCREW Price: Call Us |
| 10 |
20794 |
Pin, Valve spring retaining Price: Call Us |
| 10 |
HG2513030 |
BYPASS VALVE KIT Price: Call Us |
| 11 |
93-0688 |
DECAL-WARNING, CHEMICAL This part replaces 31274. Price: $20.09 |
| 11 |
HG70521 |
PUMP SHAFT KIT Price: Call Us |
| 12 |
29783 |
Pin, Groove Price: Call Us |
| 12 |
483948 |
BALL BEARING, 17 X 40 X 12 This part replaces HG50315. Price: Call Us |
| 13 |
27613 |
Gear, Crankshaft Price: Call Us |
| 13 |
HG51161 |
LIP SEAL Price: Call Us |
| 14 |
31304 |
Piston Pin Assy. (Incl. 2 of No. 16) (Std.) Price: Call Us |
| 14 |
31305 |
Piston Pin Assy. (Incl. 2 of No. 16) (.010 Oversize) Price: Call Us |
| 14 |
31306 |
Piston Pin Assy. (Incl. 2 of No. 16) (.020 Oversize) Price: Call Us |
| 14 |
HG50329 |
RETAINING RING Price: Call Us |
| 15 |
31443 |
DISCONTINUED Price: Call Us |
| 15 |
31484 |
Ring Set, Piston (.010 oversize) Price: Call Us |
| 15 |
31485 |
Ring Set, Piston (.020 oversize) Price: Call Us |
| 15 |
HG50951 |
SPACER Price: Call Us |
| 16 |
20381 |
Ring-Retaining, Piston Pin Price: Call Us |
| 16 |
HG70331 |
CYLINDER BLOCK KIT Price: Call Us |
| 17 |
30809 |
Rod Assy., Connecting (Incl. Nos. 18, 19 20) Price: Call Us |
| 17 |
HG2003014 |
BLOCK, SPRING Price: Call Us |
| 18 |
26706 |
Bolt, Connecting Price: Call Us |
| 18 |
HG2003017 |
DISCONTINUED Price: Call Us |
| 19 |
HG51444 |
VALVE PLATE Price: Call Us |
| 20 |
27573 |
LOCKNUT Price: Call Us |
| 20 |
HG2003087 |
SWASH PLATE Price: Call Us |
| 21 |
31317 |
Camshaft Price: Call Us |
| 21 |
HG50551 |
ROLLER THRUST BEARING Price: Call Us |
| 22 |
27241 |
Lifter-Valve Price: Call Us |
| 22 |
HG2003005 |
TRUNNION ARM Price: Call Us |
| 23 |
30756A |
Cover, Cylinder (Incl. No. 24 106) Price: Call Us |
| 23 |
HG2000015 |
SLOT GUIDE Price: Call Us |
| 24 |
28540 |
OIL SEAL Price: Call Us |
| 24 |
HG2510062 |
CHECK VALVE KIT (.024 ORIFICE) Price: Call Us |
| 25 |
27625 |
Plug-Fill, Oil Price: Call Us |
| 25 |
HG70403 |
CHARGE RELIEF KIT Price: Call Us |
| 26 |
27677 |
Gasket-Cylinder Cover Price: Call Us |
| 26 |
HG2513043 |
TRUNNION SEAL WITH RETAINER Price: Call Us |
| 27 |
30647 |
Screw Price: Call Us |
| 27 |
HG9005110-4400 |
STRAIGHT THREAD PLUG Price: Call Us |
| 28 |
30564 |
Screw Price: Call Us |
| 28 |
HG50408 |
STRAIGHT HEADLESS PIN Price: Call Us |
| 31 |
650489 |
Screw Price: Call Us |
| 32 |
29953B |
Gasket-Cylinder Head Price: Call Us |
| 33 |
30579 |
CYLINDER HEAD Price: Call Us |
| 34 |
26073 |
Washer Price: Call Us |
| 35 |
6023 |
Screw Price: Call Us |
| 36 |
6021 |
Screw Price: Call Us |
| 37 |
21943 |
SPARK PLUG Price: Call Us |
| 38 |
27234 |
Gasket-Breather Price: Call Us |
| 39 |
27666 |
Body-Breather Price: Call Us |
| 40 |
27233 |
Element, Breather Price: Call Us |
| 41 |
27667 |
Gasket-Gear Case Price: Call Us |
| 42 |
31778 |
Spring, Coil Price: Call Us |
| 43 |
650128 |
Screw Price: Call Us |
| 44 |
27627 |
Tube-Breather Price: Call Us |
| 45 |
26754 |
Gasket-Intake Price: Call Us |
| 46 |
28413 |
INTAKE PIPE Price: Call Us |
| 48 |
30646 |
Screw Price: Call Us |
| 49 |
650168 |
Washer Price: Call Us |
| 51 |
27272 |
Gasket Price: Call Us |
| 52 |
29715 |
Screw Price: Call Us |
| 53 |
590416 |
Starter Cup Price: Call Us |
| 54 |
590417 |
Screen, Air Price: Call Us |
| 55 |
31345 |
IDENTIFICATION PLATE Price: Call Us |
| 56 |
28539 |
Ring, Retainer Price: Call Us |
| 57 |
28563 |
Washer, Flat Price: Call Us |
| 58 |
31858 |
Jet-Main Price: Call Us |
| 59 |
8269 |
Lockwasher Price: Call Us |
| 60 |
31510 |
Lever-Governor Price: Call Us |
| 61 |
29142 |
Screw Price: Call Us |
| 62 |
28277 |
Washer-Flat Price: Call Us |
| 63 |
31334 |
Rod-Governor Price: Call Us |
| 64 |
30658 |
Baffle, Blower Housing (Incl. No. 65) Price: Call Us |
| 65 |
650561 |
Screw (1/4-20x19/32) Price: Call Us |
| 66 |
32078 |
INSTRUCTION DECAL Price: Call Us |
| 67 |
29309 |
DRIVE STUD Price: Call Us |
| 69 |
650556 |
Screw Price: Call Us |
| 70 |
30655 |
Housing,Blower Price: Call Us |
| 71 |
650490 |
Washer Price: Call Us |
| 72 |
650607 |
Hex Nut Price: Call Us |
| 73 |
29716 |
Screw Price: Call Us |
| 74 |
16645 |
Lockwasher Price: Call Us |
| 75 |
30747 |
Clip, Shorting Price: Call Us |
| 79 |
9577 |
Nut, Wing Price: Call Us |
| 80 |
27183 |
Washer Fibre Price: Call Us |
| 81 |
30930 |
Cleaner, Air Price: Call Us |
| 83 |
31435 |
Elbow, Air cleaner Price: Call Us |
| 84 |
111-1250 |
WHEEL 180X45 RIBBED This part replaces 6201. Price: $27.74 |
| 85 |
28569 |
SPRING, COMPRESSION Price: Call Us |
| 86 |
6674 |
Screw Price: Call Us |
| 87 |
26756 |
Gasket Price: Call Us |
| 88 |
8303 |
Lockwasher Price: Call Us |
| 89 |
29752 |
Nut and Lock Washer (1/4-28) Price: Call Us |
| 90 |
30980 |
BUSHING, CRANKSHAFT Price: Call Us |
| 91 |
30650 |
Bracket, Speed control Price: Call Us |
| 92 |
28942 |
Screw (10-32 x 3/8) Price: Call Us |
| 94 |
650116 |
LOCKNUT Price: Call Us |
| 96 |
650128 |
Screw Price: Call Us |
| 97 |
29530 |
Bushing Price: Call Us |
| 99 |
29458 |
Flange, Air cleaner Price: Call Us |
| 100 |
26460 |
Clamp-Line, Fuel Price: Call Us |
| 101 |
31335 |
Clamp-Lever, Governor Price: Call Us |
| 102 |
650548 |
Screw Price: Call Us |
| 103 |
27165 |
Gasket, Spacer Price: Call Us |
| 104 |
31438 |
Lever, Speed control Price: Call Us |
| 105 |
28458 |
BALL BEARING Price: Call Us |
| 106 |
30574 |
Shaft-Governor Price: Call Us |
| 107 |
30591 |
Gear Assy., Governor (Incl. No.132) Price: Call Us |
| 108 |
29193 |
Ring-Retaining Price: Call Us |
| 109 |
30588A |
Spool-Governor Price: Call Us |
| 111 |
29539 |
BRACKEN, FUEL TANK UPPER Price: Call Us |
| 112 |
29540 |
Bracket, Fuel tank lower Price: Call Us |
| 113 |
30529 |
Nut Price: Call Us |
| 114 |
29809 |
Tank Assy., Fuel (Incl. No. 115) Price: Call Us |
| 115 |
27799 |
Cap, Fuel tank Price: Call Us |
| 116 |
6199 |
Screw Price: Call Us |
| 117 |
29683 |
Fitting Shut-off, Fuel Price: Call Us |
| 118 |
30705 |
Line-Fuel Price: Call Us |
| 119 |
28819 |
Spring, Coil Price: Call Us |
| 120 |
650128 |
Screw Price: Call Us |
| 121 |
29745 |
Extension-Blower Price: Call Us |
| 128 |
26952 |
Screw Price: Call Us |
| 129 |
27247 |
Key Flywheel Price: Call Us |
| 130 |
31426 |
Spring-Extension Price: Call Us |
| 131 |
29443 |
Clip-Wire Price: Call Us |
| 132 |
30590A |
Washer-Flat Price: Call Us |
| 133 |
29673 |
Gasket Price: Call Us |
| 134 |
31434 |
Spacer Price: Call Us |
| 135 |
31432 |
Bracket, Speed limit Price: Call Us |
| 137 |
31436 |
Gasket, Felt Price: Call Us |
| 138 |
31437 |
Washer, Flat Price: Call Us |
| 140 |
29666 |
Screw Price: Call Us |
| 141 |
30976 |
Elbow, Breather tube Price: Call Us |
| 142 |
29786 |
Screw Price: Call Us |
| 143 |
30348 |
Clamp, Hose Price: Call Us |
| 144 |
610690 |
Magneto Price: Call Us |
| 145 |
631070A |
Carburetor Price: Call Us |
| 146 |
590420 |
Starter, Rewind Price: Call Us |
