| Ref | Part Number | Description |
|---|
| 1 |
24-6900 |
DISCONTINUED Price: Call Us |
| 1 |
530035017 |
Screw - Pump Cover Price: $0.99 |
| 2 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 2 |
530035154 |
Pump Cover Ass'y (Inc. #4) WA-79 Price: $3.33 |
| 2 |
530035191 |
Pump Cover Ass'y (Inc. #4) WA-149 Price: $3.99 |
| 3 |
3218-5 |
NUT-JAM Price: $0.27 |
| 3 |
530035135 |
Diaphragm - Pump WA-79 Price: $3.33 |
| 4 |
32102-14 |
DISCONTINUED Price: Call Us |
| 4 |
530035156 |
Screw - Idle Adjustment Price: $1.99 |
| 5 |
26-2320 |
DISCONTINUED Price: Call Us |
| 5 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 5 |
530035009 |
Gasket - Pump WA-79 Price: $1.99 |
| 6 |
256-126 |
BUSHING Price: $9.36 |
| 6 |
530035178 |
Screen - Inlet Price: $1.99 |
| 7 |
32146-13 |
NUT-HEX Price: $3.49 |
| 7 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 7 |
530035152 |
Diaphragm - Pump WA-79 Price: $5.99 |
| 8 |
12-0360 |
BALL PIVOT *R Price: $534.56 |
| 8 |
530035133 |
Valve - Throttle Price: $3.33 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
530035007 |
Clip - Throttle Shaft Price: Call Us |
| 10 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 10 |
530035138 |
Spring - Throttle Return Price: Call Us |
| 11 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 11 |
530035015 |
Screw - Throttle Valve Price: $1.99 |
| 12 |
327-4 |
SCREW-HH Price: $2.20 |
| 12 |
530035132 |
Shaft Ass'y - Throttle Price: Call Us |
| 13 |
3219-6 |
NUT-HEX Price: $2.78 |
| 13 |
530035023 |
Spring - Idle Needle Price: $0.99 |
| 14 |
3-2968 |
DISCONTINUED Price: $2.39 |
| 14 |
530035141 |
Needle - Idle Price: $2.99 |
| 15 |
3-3825 |
BALL SOCKET SHIM Price: $18.09 |
| 15 |
530035188 |
WT-141 - T1 This part replaces 530035139. Price: $1.99 |
| 16 |
3-2967 |
DISCONTINUED Price: $2.44 |
| 16 |
530035008 |
Valve - Inlet Needle Price: $3.33 |
| 17 |
3214-13 |
DISCONTINUED Price: Call Us |
| 17 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 18 |
23-5300 |
DISCONTINUED Price: Call Us |
| 18 |
530035036 |
Spring - Hi Speed Needle Price: Call Us |
| 19 |
32136-3 |
NUT-SHH Price: $1.22 |
| 19 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 20 |
3272-7 |
PIN-COTTER Price: $0.25 |
| 20 |
505520125 |
Pin This part replaces 530035028. Price: $1.99 |
| 21 |
5-2966 |
DISCONTINUED Price: Call Us |
| 21 |
530035016 |
Screw - Metering Lever Pin Price: $2.99 |
| 22 |
110-6142-03 |
LH TIE ROD END ASM This part replaces 2116-3. Price: $148.18 |
| 22 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 23 |
110-6143-01 |
TIE ROD ASM This part replaces 3-3710. Price: $513.93 |
| 23 |
530035042 |
Plate - Circuit Price: $3.33 |
| 24 |
2412-7 |
CLAMP ASM Price: $23.32 |
| 24 |
530035137 |
Screw - Circuit Plate Price: $3.33 |
| 25 |
110-6141-03 |
RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 25 |
530035151 |
Gasket - Metering Diaphragm Price: $1.99 |
| 26 |
20-9900 |
RH SPINDLE & ARM WA *R Price: $1,459.49 |
| 26 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 27 |
1528 |
BEARING-NEEDLE This part replaces 252-52. Price: $50.99 |
| 27 |
530035153 |
Screw - Ass'y - Metering Cover & Throttle Shaft Clip Price: $3.33 |
| 28 |
251-32 |
DISCONTINUED Price: Call Us |
| 28 |
530035149 |
Cover - Metering Diaphragm Price: $3.33 |
| 29 |
32136-2 |
NUT-SHH Price: $3.55 |
| 29 |
530035144 |
Kit-Carb Repair WA-79 Price: $24.99 |
| 29 |
530035185 |
Kit-Carb Repair WA-149 Price: $24.99 |
| 30 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 30 |
530035145 |
Kit-Carb Gasket/Diaphragm WA-79 Price: $14.99 |
