| Ref | Part Number | Description |
|---|
| 1 |
44-7570 |
DISCONTINUED X-REF Price: Call Us |
| 1 |
463283 |
Fuel Tank Assembly (incl. #3, 4, 5, 6, 16, 17) Price: Call Us |
| 2 |
322-4 |
SCREW-HH Price: $0.35 |
| 2 |
484286 |
Fuel Cap w/ Tether (E.P.A.) Price: Call Us |
| 3 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 4 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 4 |
484242 |
Grommet, Fuel Gauge Price: Call Us |
| 5 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 5 |
482571 |
Bushing, 0.56" Dia. Viton Price: Call Us |
| 6 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 6 |
486181 |
Valve, Fuel Shutoff w/Screen Price: Call Us |
| 7 |
43-0970 |
DISCONTINUED Price: Call Us |
| 7 |
48059-01 |
Clamp, Fuel Hose 1/4" Hose I.D. Price: Call Us |
| 8 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 9 |
323-6 |
SCREW-HH Price: $0.66 |
| 10 |
43-1040 |
DISCONTINUED Price: Call Us |
| 11 |
323-9 |
SCREW-HH Price: $1.29 |
| 12 |
43-0770 |
PULLEY WA *RO Price: $375.92 |
| 12 |
484347 |
Hose, 1/4" Vapor Recovery (order by inch) Price: Call Us |
| 13 |
04030-03 |
Lockwasher, 5/16 (.317 x .586 x .078) Helical Spring Price: Call Us |
| 13 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 14 |
04001-09 |
Bolt, Heax Head 5/16-18 x 1" (48V / 52V) Price: Call Us |
| 14 |
44-5350 |
DISCONTINUED Price: Call Us |
| 15 |
43-1030 |
V-BELT Price: $38.51 |
| 15 |
484287 |
Carbon Canister - SVR-36A / SVR-48V Price: Call Us |
| 16 |
43-1200 |
DISCONTINUED Price: Call Us |
| 16 |
484285 |
Grommet, Viton, Price: Call Us |
| 17 |
3256-16 |
WASHER-FLAT Price: $0.39 |
| 17 |
484333 |
Remote Vent, No Valve Price: Call Us |
| 18 |
43-1160 |
DISCONTINUED Price: Call Us |
| 18 |
484343-01 |
Mender, 1/4 x 3/16 w/0.02 Hole Price: Call Us |
| 19 |
43-1130 |
DISCONTINUED Price: Call Us |
| 19 |
48030-11 |
Clamp, Double Cable 5/8" ID. Price: Call Us |
| 20 |
321-4 |
SCREW-HH Price: $0.99 |
| 21 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 21 |
5-2958 |
DISCONTINUED Price: Call Us |
| 22 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 22 |
48059-05 |
Clamp, Vapor Recovery Hose 3/16" Price: Call Us |
| 23 |
43-1120 |
WARNING DECAL Price: $7.84 |
| 23 |
48059-02 |
CLAMP, FUEL HOSE(KAWASAKI ONLY) Price: Call Us |
| 24 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 25 |
44-7770-01 |
REAR SHELF WA This part replaces 44-7770. Price: $405.61 |
| 25 |
452176 |
Bracket, Canister Mounting Price: Call Us |
| 26 |
48136-17 |
Clamp, 3-1/2" Max. Dia. Price: Call Us |
| 26 |
66-1340 |
DECAL-DANGER, THROWN OBJECT This part replaces 40-5730. Price: $9.07 |
| 27 |
04003-04 |
Bolt, Carriage 5/16-18x1" (large frame units only) Price: Call Us |
| 27 |
44-5750 |
DISCONTINUED Price: Call Us |
| 28 |
92-6297-01 |
FRONT DEFLECTOR WA This part replaces 46-2350. Price: $124.99 |
| 29 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 30 |
59-5350-01 |
REAR DEFLECTOR WA This part replaces 43-1060. Price: $220.99 |
| 31 |
44-7780-01 |
RH SHELF This part replaces 44-7780. Price: $28.73 |
