| Ref | Part Number | Description |
|---|
| 1 |
146-4958 |
ASM, Deck W/ Decals, 60" Price: $1,983.99 |
| 2 |
116-3344 |
ASM-CUTTER HSG WITH BEARINGS Price: $146.99 |
| 4 |
103-6403-S |
SPK, BLADE NOTCHED 20.5 (.94 HOLE) This part replaces 103-6403. Price: $29.99 |
| 5 |
103-3037 |
BUSHING,SPLINED Price: $20.99 |
| 8 |
116-1286 |
GUARD,BEARING TOP .989 Price: $5.09 |
| 9 |
116-5614-01 |
DOGLEG - LZ60 Price: $56.99 |
| 10 |
146-4608 |
SHEAVE,BLADE DRIVE 7.25 Price: $34.99 |
| 11 |
103-2802 |
WASHER Price: $4.79 |
| 13 |
109-2872 |
SPACER-PULLEY Price: $20.99 |
| 14 |
3256-4 |
WASHER-FLAT Price: $1.49 |
| 15 |
126-2314 |
ASM, DECK IDLER Price: $178.99 |
| 16 |
3231-24 |
SCREW-CARR Price: $13.99 |
| 17 |
146-4609 |
IDLER-PULLEY, FLAT Price: $32.99 |
| 18 |
146-4625 |
Idler-Pulley, Flat Price: $43.99 |
| 19 |
146-4624 |
Pulley-Idler, Flat Price: $31.99 |
| 20 |
135-4829 |
ROD, DECK SUPPORT Price: $28.99 |
| 21 |
1-413425 |
SPACER-DECK SUPPORT Price: $5.89 |
| 22 |
1-603050 |
SPACER Price: $6.59 |
| 23 |
1-411532 |
KIT,SUPPORT LINK W/PIN This part replaces 1-414521. Price: $139.99 |
| 24 |
1-323539 |
SPACER Price: $2.09 |
| 25 |
103-2916 |
GUARD-TOP Price: $2.39 |
| 26 |
116-6317 |
SPRING-EXTENSION Price: $26.99 |
| 27 |
323-7 |
SCREW-HH Price: $2.69 |
| 28 |
109-6658 |
Nut-Nyloc 3/8-16 Flg Price: $1.19 |
| 29 |
3231-22 |
SCREW-CARR Price: $3.09 |
| 30 |
322-2 |
SCREW-HH Price: $2.29 |
| 31 |
104-8300 |
NUT-HF, NI Price: $0.89 |
| 32 |
104-8301 |
NUT-HF, NI Price: $1.19 |
| 33 |
32121-15 |
PIN-ROLL This part replaces 1-806332. Price: $1.39 |
| 34 |
323-9 |
SCREW-HH Price: $1.29 |
| 35 |
1-806009 |
PIN,HAIR COTTER Price: $2.49 |
| 36 |
116-9981 |
KIT, ANTI-SCALP ROLLER Price: $48.99 |
| 37 |
142-7105 |
SHIELD, RT Price: $24.99 |
| 38 |
142-7104 |
SHIELD, LT Price: $24.99 |
| 39 |
142-7025 |
Chute-Deck Discharge Price: $69.99 |
| 40 |
3231-40 |
BOLT-CARR, SHORT NECK Price: $2.29 |
| 41 |
126-2539-SL |
BELT, DECK DRIVE WITH SLEEVE This part replaces 126-2539. Price: $174.99 |
| 42 |
109-6982 |
WIREFORM-COVER Price: $10.99 |
| 43 |
116-9362 |
SCREW-HH 3/8-16 X 3 3/4 GR 8 Price: $2.39 |
| 44 |
116-8131 |
AXLE, ROLLER Price: $12.99 |
| 45 |
103-8415 |
ROLLER-SCALP, ANTI Price: $21.99 |
| 46 |
109-6658 |
Nut-Nyloc 3/8-16 Flg Price: $1.19 |
| 47 |
98-5975 |
WASHER-BELLEVILLE Price: $3.09 |
| 48 |
1-411532 |
KIT,SUPPORT LINK W/PIN Price: $139.99 |
| 49 |
126-8043 |
SHIELD-DUST Price: $2.39 |
| 50 |
126-9195 |
SHIELD-GUARD, DUST Price: $2.49 |
| 51 |
43-0940 |
SPACER Price: $4.89 |
| 52 |
32128-19 |
NUT-HF Price: $1.39 |
| 53 |
135-4828 |
COLLAR, DECK HEIGHT PIN Price: $16.99 |
| 54 |
32121-32 |
PIN-ROLL Price: $1.29 |
| 55 |
142-8544 |
Pin, Chute Price: $7.59 |
