| Ref | Part Number | Description |
|---|
| 1 |
3220-3 |
NUT-HJ Price: $0.28 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 2 |
93-6337 |
SCREW Price: $9.77 |
| 3 |
99-8701 |
ROTATING KIT Price: $1,722.95 |
| 4 |
105-2856 |
PISTON-SERVO Price: $739.56 |
| 5 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 6 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 7 |
105-9853 |
PLATE-COVER Price: $142.29 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 8 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 9 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 10 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 11 |
105-2858 |
VALVE-RELIEF Price: $1,100.81 |
| 13 |
323-15 |
SCREW-HH Price: $1.53 |
| 14 |
323-16 |
SCREW-HH Price: $2.89 |
| 15 |
93-6324 |
SCREW Price: $8.89 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
99-8704 |
PLATE-VALVE Price: $457.47 |
| 18 |
105-2904 |
BACKPLATE Price: $1,515.44 |
| 19 |
93-6344 |
DRIVESHAFT Price: $967.93 |
| 20 |
3217-5 |
NUT-HEX Price: $0.25 |
| 21 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 22 |
60-6240 |
WASHER Price: $15.20 |
| 23 |
93-6375 |
KEY Price: $18.32 |
| 24 |
95-2110 |
ADAPTOR Price: $1,026.64 |
| 25 |
105-2862 |
ARM-CONTROL Price: $36.88 |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $12.99 |
| 26 |
115-4446 |
CONTROL-SERVO, MANUAL Price: $1,343.56 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 27 |
93-6365 |
GEROTER-INNER Price: $124.40 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $17.99 |
| 28 |
93-6364 |
GEROTER-OUTER Price: $152.48 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 29 |
94-3041 |
ORIFICE-CONTROL (.028 DIA) Price: $26.81 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 30 |
74-9280 |
PLUG ASM Price: $35.55 |
| 31 |
105-2913 |
VALVE-BYPASS Price: $91.51 |
| 32 |
94-3030 |
WASHER Price: $6.24 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 33 |
93-6336 |
WASHER Price: $3.19 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $69.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $32.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $19.99 |
