| Ref | Part Number | Description |
|---|
| 1 |
137-6103 |
SHORT REAR ROLLER ASM (2.5IN DIA)(18IN) This part replaces 112-1708. Price: $357.70 |
| 1 |
583280801 |
SEAT.9"BLK.NO.LOGO.MILSCO This part replaces 532403017. Price: $129.99 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $5.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
532140675 |
STRAP Price: $3.99 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 6 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 7 |
112-1704 |
PLASTIC WIEHLE ROLLER ASM Price: $495.75 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 8 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
532441805 |
PAN.ASM.SEAT.SHORT.SLD.ADJ.TEX Price: $29.99 |
| 11 |
323-14 |
SCREW-HH Price: $1.34 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532199370 |
BRKT.MNT.OPC.SW.SEAT. Price: $2.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 19 |
532199372 |
KNOB.SEAT.ADJ. Price: $4.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $1.99 |
| 37 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
