| Ref | Part Number | Description |
|---|
| 1 |
93-6816 |
CONTROL-THROTTLE Price: $49.33 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 2 |
93-6743 |
STOP-THROTTLE Price: $8.04 |
| 3 |
218-594 |
FUSE-20 AMP Price: $3.02 |
| 4 |
218-578 |
FUSE-BLADE, 10 AMP Price: $2.58 |
| 5 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 6 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 7 |
93-6762 |
SWITCH-BALL Price: $132.17 |
| 8 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 9 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 10 |
3250-13 |
SCREW-PPH Price: $0.95 |
| 11 |
3274-90 |
SCREW-HSH Price: $1.53 |
| 12 |
92-9775 |
CLUSTER-LAMP, WARNING Price: $147.98 |
| 13 |
93-4411 |
GAUGE-TEMPERATURE Price: $125.82 |
| 14 |
80-6980 |
LATCH Price: $81.68 |
| 15 |
44-2212 |
AMBER INDICATOR LIGHT ASM Price: $72.17 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
92-3194 |
DISCONTINUED Price: Call Us |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
93-6902 |
DECAL-BLOCK, FUSE Price: $6.45 |
| 18 |
32149-9 |
NUT-HEX, KEPS Price: $1.15 |
| 19 |
94-3351 |
DISCONTINUED Price: Call Us |
| 19 |
94-4985 |
DECAL-PANEL, INSTRUMENT Price: $57.02 |
| 20 |
94-3691-03 |
PANEL-INSTRUMENT ASM This part replaces 94-3691. Price: $124.28 |
| 21 |
70-1480 |
RELAY Price: $105.19 |
| 22 |
32128-33 |
NUT-HF Price: $0.25 |
| 23 |
80-7345 |
DISCONTINUED Price: Call Us |
| 24 |
2412-39 |
CLAMP-R Price: $1.70 |
| 25 |
94-3692 |
DISCONTINUED Price: Call Us |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 26 |
93-6941 |
SEAL-TRIM Price: $2.36 |
| 28 |
218-535 |
NUT-HEX Price: $0.34 |
| 29 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 30 |
219-18 |
DISCONTINUED Price: Call Us |
| 31 |
218-562 |
LENS Price: $10.44 |
| 32 |
32128-44 |
NUT Price: $2.69 |
| 33 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 35 |
93-7726 |
DISCONTINUED Price: Call Us |
| 36 |
32122-35 |
SCREW Price: $35.19 |
| 37 |
219-17 |
BULB Price: $4.93 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 38 |
87-6270 |
SOCKET-LIGHT Price: $13.66 |
| 39 |
3217-26 |
NUT-HEX Price: $0.25 |
| 40 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 42 |
3218-19 |
NUT-HJ Price: $0.54 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
3298-8 |
SCREW-SET Price: $0.95 |
| 44 |
92-3195 |
KNOB Price: $14.37 |
| 45 |
3217-29 |
NUT-HEX Price: $0.25 |
| 46 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 48 |
3217-27 |
NUT-HEX Price: $0.25 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 52 |
85-5270 |
DISCONTINUED Price: Call Us |
| 53 |
66-0120 |
KNOB Price: $5.53 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
585658602 |
Stop This part replaces 585658601. Price: $4.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 587031401. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
586606502 |
PEDAL.COVER.REVERSE.CRD.X428BK Price: $17.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 325 |
585668505 |
BRACKET TORQUE STRAP This part replaces 585668502. Price: $5.99 |
| 326 |
585670803 |
BRACKET TORQUE STRAP This part replaces 585670802. Price: $4.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
