| Ref | Part Number | Description |
|---|
| 1 |
92-1374 |
SCREW-CAP,HH Price: $1.02 |
| 2 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 3 |
105-0087 |
FLANGE-FILLER, OIL Price: $54.17 |
| 4 |
98-7430 |
O-RING Price: $1.95 |
| 5 |
105-2592 |
TUBE SUPPORT ASM Price: $344.03 |
| 6 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 7 |
3257-30 |
KEY-WOODRUFF Price: $5.35 |
| 8 |
43-3690 |
SHAFT-FAN Price: $469.68 |
| 9 |
3233-14 |
SCREW-CARR Price: $1.95 |
| 10 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 11 |
105-2501-03 |
ENGINE MOUNT ASM Price: $145.54 |
| 12 |
38-7820 |
BEARING-BALL Price: $13.99 |
| 13 |
105-2524 |
PULLEY Price: $85.88 |
| 14 |
3-6803 |
WASHER-ADJUSTING Price: $0.75 |
| 15 |
29-8910 |
WASHER Price: $0.75 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
32136-3 |
NUT-SHH Price: $1.22 |
| 17 |
105-3699 |
PULLEY-IDLER, FLAT Price: $97.83 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 18 |
32128-23 |
NUT-HF Price: $1.51 |
| 19 |
105-3693 |
BELT-FAN Price: $36.77 |
| 20 |
48-9590 |
WASHER-LOCK This part replaces 42-9600. Price: $0.25 |
| 21 |
3274-106 |
SCREW-HSH Price: $5.77 |
| 22 |
104-3407-03 |
PULLEY-FLYWHEEL Price: $149.87 |
| 23 |
105-2520-03 |
ENGINE MOUNT ASM Price: $118.11 |
| 24 |
32128-37 |
NUT-HF Price: $3.63 |
| 25 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 26 |
131-1821 |
MOUNT-ENGINE This part replaces 53-9680. Price: $105.39 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 27 |
53-9480 |
WASHER-SNUBBER Price: $3.87 |
| 28 |
324-11 |
SCREW-HH Price: $3.05 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
57-6390 |
NUT-JAM Price: $0.89 |
| 30 |
33004-00 |
NUT-HF This part replaces 92-6780. Price: $0.34 |
| 31 |
56-2140 |
SCREW-HH Price: $4.17 |
| 32 |
105-0058 |
SPACER-IDLER, FAN Price: $6.72 |
| 33 |
105-2502 |
STUD Price: $5.97 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 34 |
105-4263 |
SWIVEL-CABLE, THROTTLE Price: $36.98 |
| 35 |
105-2507-03 |
CRADLE-SUPPORT, TUBE Price: $180.52 |
| 35 |
583864502 |
Rods This part replaces 583864501. Price: $6.99 |
| 36 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 37 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 37 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 38 |
25-8640 |
SCREW-HH Price: $1.09 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 69 |
583404901 |
HAIRPIN.SOFT.ZINC.059X1.125 This part replaces 532423303. Price: $2.99 |
| 73 |
596136501 |
Bolts This part replaces 874490540. Price: $3.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
582404501 |
ARM.PIVOTING.TCRD.GEN2.5.BAGGE Price: $5.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532448275. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 587653701. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 587031401. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532421263 |
PEDAL.FORWARD.PAD.TEX Price: $6.99 |
| 215 |
586606502 |
PEDAL.COVER.REVERSE.CRD.X428BK Price: $17.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 227 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 325 |
585668505 |
BRACKET TORQUE STRAP This part replaces 585668502. Price: $5.99 |
| 326 |
585670803 |
BRACKET TORQUE STRAP This part replaces 585670802. Price: $4.99 |
| 336 |
587259602 |
Bolts This part replaces 587259601. Price: $3.99 |
