| Ref | Part Number | Description |
|---|
| 1 |
2751R |
CLIP T Price: Call Us |
| 1 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 2 |
122018X |
BRKT CLUTCH Price: Call Us |
| 3 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 3 |
74780408 |
BOLT Price: Call Us |
| 4 |
110-0009 |
JOINT ARM ASM This part replaces 106-5437-03. Price: $199.32 |
| 4 |
73680600 |
SUB= 73690600 Price: Call Us |
| 5 |
104-9319 |
PIN-GROOVED Price: $6.58 |
| 5 |
123417X |
CLUTCH LEVER AS Price: Call Us |
| 6 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 7 |
123491X |
CLUTCH ARM ASS'Y Price: Call Us |
| 8 |
74760636 |
BOLT Price: Call Us |
| 10 |
105-7512 |
PIN-TIE, BOW Price: $4.27 |
| 10 |
76020412 |
COTTER PIN Price: Call Us |
| 11 |
19131316 |
WASHER Price: Call Us |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 12 |
122027X |
GRIP HANDLE Price: Call Us |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 13 |
122741X |
LIFT HANDLE ASS'Y Price: Call Us |
| 14 |
123496X |
SPRING COMPRESSIO Price: Call Us |
| 14 |
92-9097 |
SCREW-HS Price: $1.56 |
| 15 |
19131212 |
WASHER T Price: Call Us |
| 15 |
93-0142 |
BUSHING-STRAIGHT Price: $3.21 |
| 16 |
76020412 |
COTTER PIN Price: Call Us |
| 16 |
94-4919-03 |
BRACKET-CLAMP, HOSE Price: $19.76 |
| 17 |
123654X |
LINK FRT LIFT Price: Call Us |
| 17 |
322-13 |
SCREW-HH Price: $2.73 |
| 18 |
7078J |
SUB= 142028 Price: Call Us |
| 18 |
75-4520 |
SPRING-TORSION, RH Price: $25.31 |
| 19 |
73350600 |
NUT Price: Call Us |
| 19 |
75-4530 |
SPRING-TORSION, LH Price: $25.31 |
| 20 |
74760644 |
BOLT Price: Call Us |
| 21 |
17490508 |
SCREW LT Price: Call Us |
| 22 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
100-3828 |
DISCONTINUED Price: Call Us |
| 23 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 24 |
100-3827 |
LH REAR LIFT ARM ASM Price: $720.05 |
| 24 |
19171616 |
WASHER Price: Call Us |
| 25 |
121933X |
TUBE SPACER Price: Call Us |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
19131316 |
WASHER Price: Call Us |
| 27 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 28 |
76020312 |
SUB= 3145 Price: Call Us |
| 29 |
121466X |
KNOB Price: Call Us |
| 29 |
84-2451 |
CHAIN-STRAIGHT, 5 LINK Price: $9.25 |
| 30 |
100-3834-03 |
ROD-PIVOT Price: $69.13 |
| 31 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 32 |
93-3640 |
STOP-RH Price: $12.61 |
| 33 |
83-5170 |
DISCONTINUED Price: Call Us |
