| Ref | Part Number | Description |
|---|
| 1 |
429695 |
Screen Inlet Price: Call Us |
| 2 |
429610 |
Battery Bracket Price: Call Us |
| 3 |
429827 |
Battery Support Price: Call Us |
| 4 |
481885-03 |
Knob, Tracking Adjustment Price: Call Us |
| 5 |
453474 |
Panel Weldment - RH Price: Call Us |
| 6 |
04024-02 |
Nut, Push-On - 3/8" Dia. Price: Call Us |
| 7 |
04117-01 |
Nut, Flange Head Elastic Stop 5/16-18 Price: Call Us |
| 8 |
463631 |
Front Cover w/Decal Price: Call Us |
| 9 |
429834 |
Upper Cover Price: Call Us |
| 10 |
04003-04 |
Bolt, Carriage 5/16-18x1" (large frame units only) Price: Call Us |
| 11 |
481284 |
Bumper, Rubber 5/16-18 x 5/8" Price: Call Us |
| 12 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 13 |
453622 |
Front Plate Price: Call Us |
| 14 |
463672 |
Frame W/Decals Price: Call Us |
| 15 |
429831 |
Drain Cover Price: Call Us |
| 16 |
453473 |
Panel Weldment - LH Price: Call Us |
| 17 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 18 |
4200351 |
Cable Bracket Price: Call Us |
| 19 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 20 |
04017-16 |
Capscrew, 5/16-18 x .75 Serrated Flange Hex Head Price: Call Us |
| 21 |
04003-37 |
Bolt, Carriage 5/16-18 x 1-1/4" Price: Call Us |
| 22 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 23 |
463650 |
Cushion Bracket W/Decal Price: Call Us |
| 24 |
487595 |
Front Cushion Price: Call Us |
| 25 |
487608 |
Side Cushion Price: Call Us |
| 26 |
04023-08 |
Weld Nut Pilot 3/8 - 16 Price: Call Us |
| 27 |
486758 |
Isolator, Footplate Price: Call Us |
| 28 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 29 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 30 |
487855 |
Switch, DP NC/NC Two Pole Shorting Price: Call Us |
| 31 |
429351 |
Switch Bracket, OPC Switch Price: Call Us |
| 32 |
04001-18 |
Bolt, Hex Head, 3/8-16 x 3/4" Price: Call Us |
| 33 |
04001-45 |
Capscrew, Hex Head 3/8-16 x 2.0" Price: Call Us |
| 34 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 35 |
48755 |
Spring,Counter Balance Price: Call Us |
| 37 |
486834 |
Bearing, Pivot Price: Call Us |
| 38 |
43572 |
Yoke, Front Caster Wheel Price: Call Us |
| 39 |
04017-28 |
CAPSCREW, 3/16 X 1-1/4" SERRATED FLANGE Price: Call Us |
| 40 |
04003-11 |
SHORT SQ. NECK CARRIAGE BOLT, 3/8-16 X 1-1/4" Price: Call Us |
| 41 |
481885-06 |
Knob, 5/16-18 Price: Call Us |
