| Ref | Part Number | Description |
|---|
| 1 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 1 |
532170771 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
108-6557 |
STEER VALVE AND COLUMN ASM This part replaces 63-9250. Price: $1,800.82 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 4 |
54-8970 |
U-BOLT Price: $11.66 |
| 5 |
24-2000 |
DISCONTINUED Price: Call Us |
| 5 |
532191548 |
EXHAUST.TUBE.MUFFLR.LH.VANG Price: $69.99 |
| 6 |
24-2090 |
STEERING WHEEL CAP Price: $30.55 |
| 6 |
532191549 |
EXHAUST.TUBE.MUFFLR.RH.VANG Price: $39.99 |
| 7 |
3220-6 |
NUT-JAM Price: $1.25 |
| 8 |
233-17 |
KNOB Price: $10.58 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
63-7910 |
ROD-BRAKE, PARKING Price: $40.67 |
| 10 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 12 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 13 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 16 |
108-1377 |
BRAKE CABLE ASM, RH This part replaces 63-7730. Price: $157.02 |
| 17 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 19 |
63-6750 |
LINK-CABLE, BRAKE Price: $6.39 |
| 20 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 21 |
321-3 |
SCREW-HH Price: $0.28 |
| 22 |
63-6210-03 |
PIN-BRAKE This part replaces 63-6210. Price: $66.77 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 25 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 25 |
532161729 |
CONTROL.CHOKE.40"BLACK Price: $22.99 |
| 26 |
63-6180 |
PEDAL-BRAKE, LH Price: $209.48 |
| 26 |
873920600 |
Nut Keps 3/8-24 unf Price: $3.99 |
| 27 |
256-42 |
BUSHING Price: $7.03 |
| 28 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 29 |
63-6190 |
PEDAL-BRAKE, RH Price: $209.48 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 31 |
66-8140 |
HOSE-HYDRAULIC Price: $55.60 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 32 |
66-8630 |
TUBE-HYDRAULIC Price: $104.22 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 33 |
66-8620 |
TUBE-HYDRAULIC Price: $125.76 |
| 34 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 35 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 36 |
237-30 |
O-RING Price: $2.50 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 37 |
66-8170 |
HOSE ASM Price: $100.76 |
| 38 |
237-22 |
O-RING Price: $2.43 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
