| Ref | Part Number | Description |
|---|
| 1 |
139-6593-05 |
PLATE-HOC, LH (2 HOLE) Price: $15.31 |
| 2 |
139-6592-05 |
PLATE-HOC, RH (2 HOLE) Price: $15.31 |
| 3 |
137-3052 |
SCREW-HH Price: $0.34 |
| 4 |
119-4038 |
NUT-HEX Price: $0.31 |
| 5 |
100-1445 |
BOLT-CARR Price: $0.33 |
| 6 |
139-1724 |
NUT-LOCK Price: $0.32 |
| 7 |
132-4486 |
ARM-SPRING Price: $9.32 |
| 8 |
110-0549 |
KNOB-HOC Price: $1.08 |
| 9 |
139-5451 |
ARM-PIVOT, REAR Price: $7.98 |
| 10 |
108-9779 |
RETAINER-BUSHING, HOC Price: $9.09 |
| 11 |
104-8699 |
BEARING-BALL Price: $3.28 |
| 12 |
108-9782 |
BUSHING-SLEEVE Price: $2.32 |
| 16 |
120-9676 |
SCREW-PLASTITE Price: $0.34 |
| 17 |
110-7191 |
WASHER-THRUST Price: $1.79 |
| 18 |
131-5399 |
GEAR-PINION, 15T Price: $2.67 |
| 19 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 20 |
140-2362 |
ASM-COVER, GEAR (DK GRAY) Price: $2.62 |
| 22 |
140-2350 |
ASM-9.65" WHEEL, GEARED Price: $22.97 |
| 23 |
139-1789 |
WHEEL BOLT Price: $1.08 |
| 24 |
130-6709 |
COVER-BELT, REAR Price: $10.34 |
| 25 |
137-3099 |
SCREW-PLASTITE, HWH Price: $0.61 |
| 26 |
139-6597 |
SHIELD-TRAILING Price: $6.55 |
| 29 |
140-2370 |
TRANSMISSION-AWD Price: $75.32 |
| 30 |
140-2380 |
BELT-AWD, 34.50 Price: $16.41 |
| 31 |
140-2371-03 |
GUIDE-BELT, AWD Price: $4.37 |
| 32 |
140-2369 |
PAD-SMART STOW Price: $0.65 |
| 33 |
137-9137 |
SCREW-PPH Price: $0.70 |
