| Ref | Part Number | Description |
|---|
| 1 |
710-04379A |
Hex Head Screw, 7/16-20 x 3.50 Price: $5.35 |
| 2 |
725-06019 |
Clutch Wire Jumper Price: $27.95 |
| 2 |
917-05123A |
Electric PTO Clutch This part replaces 917-05123. Price: $558.78 |
| 3 |
725-0157 |
Cable Tie, 3/16 x .05 x 7.4 Price: $3.46 |
| 4 |
736-0322 |
Washer, Flat, .450 x 1.25 x .164 Price: $8.42 |
| 5 |
736-0277 |
Flat Washer, 1.031 x 1.620 x .095 Price: $3.90 |
| 6 |
683-04469D-0637 |
LOWER FRAME ASSEMBLY(POWDER BLACK) Not Available Price: |
| 7 |
756-0978B |
Electric PTO Engine Pulley Price: $58.13 |
| 8 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 9 |
710-3005 |
Hex Head Screw, 3/8-16 x 1.25 Price: $3.61 |
| 10 |
712-04065 |
Flangelock Nut, 3/8-16 Price: $3.68 |
| 11 |
738-04058 |
Shoulder Spacer, .38 x 1.0 x .70 Price: $3.86 |
| 12 |
747-04121A |
Battery Holder Rod Price: $5.52 |
| 13 |
783-0349-0637 |
BATTERY TRAY Not Available Price: |
| 14 |
783-06089-0637 |
SEAT FRAME BRACKET (POWDER BLACK) Not Available Price: |
| 15 |
683-04219B-0637 |
Bumper Price: $53.16 |
| 16 |
712-0130 |
Hex Lock Nut, 3/8-16 Price: $3.61 |
| 17 |
731-08049A |
BUMPER/HUB CAP Not Available This part replaces 731-08049. Price: |
| 18 |
738-0143 |
SHOULDER SCREW .498 DIA x .340 Price: $3.93 |
| 19 |
714-04061 |
Quick Release Pin Price: $19.21 |
| 20 |
710-04666 |
Hex Head Flange, 1/4-20 x .75 Price: $6.04 |
| 21 |
712-0271 |
Sems Nut, 1/4-20 Price: $3.78 |
| 22 |
925-1707D |
BATTERY Not Available Price: |
| 23 |
710-0653 |
Taptite Screw, 1/4-20 x 0.375 Price: $3.78 |
| 24 |
712-04064 |
Flangelock Nut, 1/4-20 Price: $3.64 |
| 25 |
725-04363 |
Interlock Switch Price: $13.25 |
| 27 |
738-04237A |
Shoulder Screw, #10-32 x .500 Price: $5.30 |
| 28 |
747-05195 |
Belt Keeper Rod Price: $31.37 |
| 29 |
732-0814 |
Spr, Extn, .56 Dia X 5.52 Price: $7.29 |
