| Ref | Part Number | Description |
|---|
| 1 |
112-0378 |
BRACKET-RETAIN, HOOK Price: $6.01 |
| 2 |
112-0370 |
SPINDLE ASM Price: $98.48 |
| 3 |
112-0413 |
LH HANGER BRACKET ASM Price: $38.86 |
| 4 |
112-0702 |
DISCONTINUED Price: Call Us |
| 5 |
112-5859 |
DECK AND DECAL ASM Price: $831.54 |
| 6 |
112-0854 |
STOP-CHUTE Price: $74.13 |
| 7 |
112-0513 |
SCREW-HH Price: $3.52 |
| 8 |
112-0590 |
SCREW-HH Price: $3.52 |
| 9 |
112-0373 |
SCREW-HH Price: $3.50 |
| 10 |
112-0524 |
SCREW-HWHTF Price: $3.48 |
| 11 |
112-0472 |
SCREW-HH, TAP Price: $3.42 |
| 12 |
112-0395 |
SCREW-HWH Price: $6.55 |
| 13 |
112-0631 |
SCREW-HH Price: $3.52 |
| 14 |
112-0452 |
BOLT-CARR Price: $3.52 |
| 15 |
112-0572 |
WASHER-FLAT Price: $3.52 |
| 16 |
112-0668 |
NUT-LOCK, FLANGE Price: $3.38 |
| 17 |
112-0330 |
NUT-LOCK, FLANGE Price: $5.46 |
| 19 |
112-0385 |
NUT-LOCK, FLANGE Price: $3.48 |
| 22 |
112-0533 |
CHUTE ASM Price: $101.18 |
| 23 |
112-0412 |
PIN-COTTER Price: $3.50 |
| 25 |
112-0327 |
GEAR-ADJUSTMENT, DECK Price: $12.35 |
| 26 |
112-0505 |
PULLEY-DECK Price: $35.04 |
| 27 |
112-0406 |
SPRING-COMPRESSION Price: $6.37 |
| 28 |
112-0349 |
SPRING Price: $17.24 |
| 29 |
112-0677 |
WHEEL-DECK, FRONT Price: $16.41 |
| 30 |
112-0337 |
WHEEL-DECK, REAR Price: $10.93 |
| 31 |
112-0366 |
DISCONTINUED Price: Call Us |
| 32 |
112-0623 |
RETAINER-BOLT Price: $3.52 |
| 33 |
112-0564 |
WASHER-FLAT Price: $3.67 |
| 34 |
112-0926 |
FITTING-GREASE Price: $3.63 |
| 35 |
112-0334 |
BOLT-SHOULDER Price: $7.65 |
| 36 |
112-6184 |
BOLT SHOULDER ASM This part replaces 112-5836. Price: $21.23 |
| 37 |
112-0316 |
BLADE-17.90 INCH Price: $29.54 |
| 38 |
112-0436 |
PIN-HANDLE, DECK RELEASE Price: $10.77 |
| 39 |
112-0612 |
SKIRT-RH Price: $22.30 |
| 40 |
112-0332 |
BELT-V, TYPE B Price: $100.68 |
| 41 |
112-0314 |
PULLEY-IDLER Price: $37.20 |
| 42 |
112-5837 |
SKIRT-CENTER Price: $25.83 |
| 43 |
112-0614 |
DISCONTINUED Price: Call Us |
| 44 |
112-0618 |
DISCONTINUED Price: Call Us |
| 45 |
112-0437 |
NUT-HEX Price: $3.50 |
| 46 |
112-0650 |
NUT-LOCK, FLANGE Price: $3.42 |
| 47 |
112-0691 |
SPACER Price: $8.78 |
| 48 |
112-0682 |
PIN-ROLLER This part replaces 112-5839. Price: $21.81 |
| 49 |
112-0521 |
ROLLER-FRONT This part replaces 112-5840. Price: $30.16 |
