| Ref | Part Number | Description |
|---|
| 1 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 1 |
530054429 |
Handle Price: $7.99 |
| 2 |
3217-7 |
NUT-HEX Price: $0.28 |
| 2 |
530054432 |
Isolator-Handle Price: $3.99 |
| 3 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 3 |
530016316 |
Nut Price: $1.99 |
| 4 |
32140-34 |
DISCONTINUED X-REF Price: Call Us |
| 4 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 5 |
3-8602 |
DISCONTINUED Price: Call Us |
| 5 |
530055336 |
Shroud Price: $17.99 |
| 6 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 6 |
530055378 |
Shield-Heat Price: $4.99 |
| 7 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
530015805 |
Screw Price: $1.99 |
| 8 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 8 |
530016349 |
Screw Price: $1.99 |
| 9 |
3-8718 |
DISCONTINUED Price: Call Us |
| 9 |
530071472 |
Gasket-Carb. (Kit) Price: $6.99 |
| 10 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 10 |
530052333 |
Air Box Price: $2.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
530015123 |
Washer This part replaces 530015158. Price: $1.99 |
| 12 |
3-8601 |
DISCONTINUED Price: Call Us |
| 12 |
530015892 |
Screw Price: $1.99 |
| 13 |
5-1640 |
DISCONTINUED Price: Call Us |
| 13 |
530052332 |
Cover-Air Box Price: $1.99 |
| 14 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 14 |
530047932 |
Foam-Air Filter Price: $1.99 |
| 15 |
3220-3 |
NUT-HJ Price: $0.28 |
| 15 |
530016394 |
Screw Price: $3.33 |
| 16 |
5-1637 |
DISCONTINUED Price: Call Us |
| 16 |
530071629 |
Kit-Carburetor Ass'y. (C1U-W12A) Price: $54.99 |
| 17 |
5-1660 |
DISCONTINUED Price: Call Us |
| 17 |
530057725 |
Foam-Air Dam Price: $2.99 |
| 18 |
530016309 |
Screw Price: $1.99 |
| 18 |
8-5129 |
DISCONTINUED This part replaces 4-4359. Price: Call Us |
| 19 |
38-7410 |
DISCONTINUED This part replaces 3-8597. Price: Call Us |
| 19 |
530057634 |
Adaptor-Carb. Price: $8.99 |
| 20 |
5-3894 |
DISCONTINUED Price: Call Us |
| 20 |
530071472 |
Gasket-Cyl/Carb. Adaptor (Kit) Price: $6.99 |
| 21 |
530071472 |
Gasket-C'case/Shroud (Kit) Price: $6.99 |
| 22 |
352-276 |
DISCONTINUED Price: Call Us |
| 23 |
352-272 |
DISCONTINUED Price: Call Us |
| 23 |
530071625 |
C'case & C'shaft Ass'y. This part replaces 530052344. Price: $39.99 |
| 24 |
352-273 |
DISCONTINUED Price: Call Us |
| 25 |
352-268 |
DISCONTINUED Price: Call Us |
| 25 |
530015941 |
Retainer Ring (C'shaft) Price: $1.99 |
| 26 |
352-278 |
DISCONTINUED Price: Call Us |
| 26 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 27 |
352-279 |
DISCONTINUED Price: Call Us |
| 27 |
545081702 |
KIT FAN HSG This part replaces 530055335. Price: $11.99 |
| 28 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 28 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 29 |
352-270 |
DISCONTINUED Price: Call Us |
| 30 |
3-8716 |
DISCONTINUED Price: Call Us |
| 30 |
530032125 |
Inner Bearing Price: $11.99 |
| 31 |
3-8657 |
DISCONTINUED Price: Call Us |
| 31 |
530019264 |
Seal-Crankcase Price: $2.99 |
| 32 |
323-7 |
SCREW-HH Price: $0.65 |
| 32 |
530055728 |
Bearing-Outer Price: $6.99 |
| 33 |
5-1651 |
DISCONTINUED Price: Call Us |
| 33 |
530071472 |
Gasket-Cylinder (Kit) Price: $6.99 |
| 34 |
3-8596 |
SPRING-COMPRESSION Price: $29.97 |
| 34 |
530039163 |
Ignition Module Price: $34.99 |
| 35 |
5-3942 |
DISCONTINUED Price: Call Us |
| 35 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 36 |
5-1664 |
DISCONTINUED Price: Call Us |
| 36 |
530016357 |
Screw Price: $1.99 |
| 37 |
5-1865 |
DISCONTINUED Price: Call Us |
| 37 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 38 |
3231-24 |
SCREW-CARR Price: $1.36 |
| 39 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 39 |
530015162 |
Wrist Pin Retainer Price: $1.99 |
| 40 |
3-8663 |
DISCONTINUED Price: Call Us |
| 40 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 41 |
3-8623 |
DISCONTINUED Price: Call Us |
| 42 |
28-1520 |
DISCONTINUED This part replaces 6-1200. Price: Call Us |
| 42 |
530015953 |
Screw Price: $1.99 |
| 43 |
3-8595 |
DISCONTINUED Price: Call Us |
| 43 |
530012500 |
Cylinder Price: $12.99 |
| 44 |
5-3941 |
DISCONTINUED Price: Call Us |
| 44 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 45 |
3-8607 |
DISCONTINUED Price: Call Us |
| 45 |
530071472 |
Gasket-Muffler (kit) Price: $6.99 |
| 46 |
5-3953 |
DISCONTINUED Price: Call Us |
| 47 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 47 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 48 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 48 |
530071544 |
Kit-Spark Aresstor Price: $6.99 |
| 49 |
5-1705 |
END SKID ASM Price: $139.95 |
| 49 |
530015241 |
Screw Price: $1.99 |
| 50 |
5-3965 |
DISCONTINUED Price: Call Us |
| 51 |
323-6 |
SCREW-HH Price: $0.66 |
| 52 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 53 |
5-3824 |
DISCONTINUED Price: Call Us |
| 54 |
3245-31 |
SCREW-HSH Price: $12.15 |
| 55 |
5-3835 |
DISCONTINUED Price: Call Us |
| 56 |
5-3950 |
DISCONTINUED Price: Call Us |
| 57 |
11-4929 |
DISCONTINUED This part replaces 5-3944. Price: Call Us |
| 58 |
5-2186 |
REEL BEARING Price: $45.95 |
| 59 |
5-3838 |
DISCONTINUED Price: Call Us |
| 60 |
253-121 |
DISCONTINUED Price: Call Us |
| 61 |
5-2182 |
DISCONTINUED Price: Call Us |
| 62 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 63 |
3296-45 |
NUT-HEX Price: $3.79 |
| 64 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 65 |
5-3915 |
DISCONTINUED Price: Call Us |
| 66 |
5-3918 |
DISCONTINUED Price: Call Us |
| 67 |
5-3837 |
DISCONTINUED Price: Call Us |
| 68 |
5-3966 |
DISCONTINUED Price: Call Us |
| 69 |
5-1704 |
DISCONTINUED Price: Call Us |
| 70 |
5-1650 |
DISCONTINUED Price: Call Us |
| 71 |
3-8634 |
DISCONTINUED Price: Call Us |
| 72 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 73 |
3-8635 |
DISCONTINUED Price: Call Us |
| 74 |
3253-9 |
WASHER-LOCK Price: $1.02 |
| 75 |
3218-7 |
NUT-JAM Price: $3.86 |
| 76 |
3279-2 |
DISCONTINUED Price: Call Us |
| 77 |
352-277 |
DISCONTINUED Price: Call Us |
