| Ref | Part Number | Description |
|---|
| 1 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 2 |
530035151 |
Metering Diaphragm Gasket Price: $1.99 |
| 3 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 3 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 4 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 4 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 5 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 5 |
530035036 |
Hi Speed Needle Spring Price: Call Us |
| 6 |
106-9758 |
SCREW-CARR Price: $2.99 |
| 6 |
530035141 |
Idle Needle Price: $2.99 |
| 7 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 7 |
530035023 |
Idle Needle Spring Price: $0.99 |
| 8 |
112-7451 |
SCREW-TAP Price: $2.17 |
| 8 |
530035203 |
Idle Speed Screw Price: $5.99 |
| 9 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 9 |
501667801 |
Spring This part replaces 530035208. Price: $1.99 |
| 10 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 10 |
505520125 |
Pin This part replaces 530035028. Price: $1.99 |
| 11 |
322-16 |
SCREW-HH Price: $3.39 |
| 11 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
| 12 |
530035188 |
Metering Lever Spring Price: $1.99 |
| 13 |
503117001 |
Needle This part replaces 530035106. Price: $7.99 |
| 14 |
530035178 |
Inlet Screen Price: $1.99 |
| 15 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 16 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 17 |
530035260 |
Carb. Kwik Repair Kit (Inc. 1,2,3,12,13,14, 15,16,18) Price: $14.99 |
