| Ref | Part Number | Description |
|---|
| 1 |
KH-20-468-03-S |
THRUST WASHER Not Available Price: |
| 2 |
149723 |
Muffler Price: Call Us |
| 3 |
KH-20-144-11-S |
Kit,Cam Center Shaft (Exhaust) Price: $20.36 |
| 5 |
KH-20-123-02-S |
Tube, Drainback Price: $4.72 |
| 6 |
KH-20-041-21-S |
GASKET-CLOSURE PLATE Not Available This part replaces KH-20-041-01-S. Price: |
| 7 |
KH-20-086-06-S |
Screw, Shd Thd Frm M6X1X26 Price: $3.69 |
| 9 |
194320 |
Keeper Asm. Belt Engine Price: Call Us |
| 9 |
KH-62-018-04-S |
Retainer, Piston Pin Price: $2.06 |
| 10 |
KH-20-108-04-S |
Ring Set (94Mm) Price: $61.73 |
| 11 |
179335 |
Clutch Electric Price: Call Us |
| 12 |
194343 |
Pulley Engine Price: Call Us |
| 12 |
KH-62-018-04-S |
Retainer, Piston Pin Price: $2.06 |
| 13 |
KH-20-067-05-S |
CONNECTING ROD ASSEMBLY Not Available Price: |
| 14 |
KH-20-032-08-S |
OIL SEAL Not Available This part replaces KH-20-032-01-S. Price: |
| 15 |
193499 |
Tank Fuel 4.0 Price: Call Us |
| 15 |
KH-25-139-57-S |
Plug, Sq Hd Pipe 3/8" Price: $2.29 |
| 17 |
KH-20-086-06-S |
Screw, Shd Thd Frm M6X1X26 Price: $3.69 |
| 18 |
195951 |
Cap Asm Price: Call Us |
| 18 |
KH-20-086-12-S |
SHOULDER SCREW Not Available This part replaces KH-20-112-02-S. Price: |
| 19 |
KH-20-086-12-S |
SHOULDER SCREW Not Available This part replaces KH-20-086-13-S. Price: |
| 20 |
175437X428 |
Control Throttle Price: Call Us |
| 21 |
191611 |
Screw 10 x 3/4 Single Lead-Hex Price: Call Us |
| 21 |
KH-12-154-05-S |
HITCH PIN CLIP This part replaces KH-12-154-05. Price: $2.11 |
| 22 |
187767X428 |
Control Choke Price: Call Us |
| 22 |
KH-X-25-102-S |
WASHER-PLAIN 1/4 Not Available Price: |
| 23 |
KH-M-631015-S |
Flat Washer, 6 Mm This part replaces KH-M-631015. Price: $2.29 |
| 24 |
KH-20-144-02-S |
Shaft, Governor Cross Price: $13.66 |
| 26 |
KH-20-468-03-S |
THRUST WASHER Not Available Price: |
| 27 |
KH-20-089-06-S |
SPRING-ACR Not Available Price: |
| 28 |
401135 |
Fuel Line Price: Call Us |
| 28 |
KH-20-044-32-S |
KIT-ACR WEIGHT Not Available This part replaces KH-20-044-16-S. Price: |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 31 |
145006 |
Clip Push-In Hinged Price: Call Us |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 41 |
126197X |
Washer 1-1/2 OD x 15/32 ID x .250 Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 62 |
146629 |
Shield Heat Muffler Price: Call Us |
| 69 |
165391 |
Gasket Price: Call Us |
| 70 |
159955 |
Tube Exhaust LH Price: Call Us |
| 71 |
160589 |
Tube Exhaust RH Price: Call Us |
| 79 |
183906 |
Screw Socket Head Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 84 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 85 |
179953 |
Bolt Hex 7/16-20 x 3.75 Gr. 5 Price: Call Us |
| 87 |
198239 |
Bolt 5/16-18 unc x 1 w/Sems Price: Call Us |
