| Ref | Part Number | Description |
|---|
| 1 |
GW-96515 |
CABLE-BATTERY 10" This part replaces 96515. Price: $13.84 |
| 2 |
GW-97020 |
BOOT-BATTERY CABLE Not Available This part replaces 97020. Price: |
| 3 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 9552. Price: $3.86 |
| 4 |
1186309 |
SCREW-FLANGE Not Available Price: |
| 7 |
777S30648 |
Label, Ignition Switch This part replaces 1904548. Price: $4.25 |
| 9 |
925-0201 |
Key This part replaces 96520. Price: $8.70 |
| 10 |
1186073 |
Carriage Screw, 1/4-20 x 1.25 This part replaces GW-9566. Price: $2.67 |
| 11 |
936-0329 |
Lock Washer This part replaces 1100241. Price: $3.90 |
| 12 |
1186229 |
Nut-hex, 1/4"-20 Price: $4.05 |
| 15 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 16 |
912-3057 |
NUT-5/16X 24 This part replaces 1186211. Price: $5.94 |
| 17 |
1187559 |
WASHER-#10 Not Available Price: |
| 18 |
1186208 |
Nut-hex, #10-32 Not Available Price: |
| 19 |
GW-96510 |
Cable (solenoid to starter motor) This part replaces 96510. Price: $10.43 |
| 20 |
GW-2571 |
BRKT-BATTERY OPC PNT This part replaces 2571. Price: $113.38 |
| 21 |
1186349 |
Bolt-flanged hex hd., 3/8-16 x 1-1/2" Price: $3.11 |
| 23 |
GW-9265 |
TIE-TWIST LOCK Not Available This part replaces 9265. Price: |
| 24 |
9009 |
Vent Tube-5/16" diameter Price: Call Us |
| 25 |
1475 |
Shield-vent tube, 1/2" diameter Price: Call Us |
| 26 |
9224 |
Clamp-vent tube shield Price: Call Us |
| 30 |
1186389 |
Locknut-hex, 1/4"-20 Price: $3.05 |
| 31 |
N/A |
UNKNOWN |
| 32 |
1901202 |
Cable-ground, solenoid to engine block Price: $30.69 |
| 33 |
710-04048 |
SCREW 5/16-18 x 1 GR5 This part replaces 1186331. Price: $4.19 |
| 34 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
