| Ref | Part Number | Description |
|---|
| 1 |
130-7092-03 |
TANK SADDLE ASM Price: $1,847.88 |
| 1 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 2 |
117-8005 |
TANK ASM Price: $2,772.40 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532175131. Price: $59.99 |
| 3 |
131-3744-03 |
MOUNT-VALVE Price: $388.91 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
104-7102 |
PAD-BATTERY Price: $3.53 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
327-4 |
SCREW-HH Price: $2.20 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
32128-50 |
NUT-FLANGE Price: $1.78 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 12 |
132-4297 |
BYPASS HOSE ASM This part replaces 131-5774. Price: $229.84 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
108-0069 |
VALVE-BALL Price: $154.28 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
110-5224 |
FITTING-BARBED, STRAIGHT Price: $5.40 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
112-7900 |
MOUNT-PEG Price: $45.88 |
| 17 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180641. Price: $59.99 |
| 17 |
62-1230 |
WASHER-RUBBER Price: $5.39 |
| 18 |
322-3 |
SCREW-HH Price: $0.79 |
| 19 |
98-0979 |
LYNCH PIN ASM Price: $20.82 |
| 20 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 21 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $4.99 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM This part replaces 532130465. Price: $29.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532100711. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532407600 |
KIT.RPLMNT.SHAFT.STRG. This part replaces 532180640. Price: $59.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 51 |
873540400 |
NUT.CROWNLOCK.1/4-28 Price: $4.99 |
| 54 |
871130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: $4.99 |
| 63 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 85 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
