| Ref | Part Number | Description |
|---|
| 1 |
67-3990 |
LEVER ASSEMBLY Price: $41.40 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
67-4000 |
DISCONTINUED Price: Call Us |
| 3 |
67-4270 |
BOLT Price: $0.89 |
| 4 |
67-4130 |
GOVERNOR COVER Price: $102.33 |
| 5 |
67-4160 |
GASKET Price: $4.78 |
| 6 |
42-8830 |
O-RING Price: $2.96 |
| 7 |
75-4980 |
GOVERNOR SPRING LEVER Price: $8.05 |
| 8 |
67-3260 |
WASHER Price: $1.58 |
| 9 |
42-9640 |
JAM NUT Price: $4.69 |
| 9 |
532408667 |
KEEPER BELT ENGINE Price: $9.99 |
| 10 |
42-8830 |
O-RING Price: $2.96 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 11 |
67-4140 |
LEVER ASSEMBLY Price: $76.30 |
| 12 |
42-9430 |
SCREW-HH Price: $0.30 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
67-4040 |
WEIGHT ASSEMBLY Price: $98.67 |
| 15 |
599306202 |
TANK ASSY W/CAP REAR CARB This part replaces 532422948. Price: $249.99 |
| 15 |
67-4010 |
STOPPER Price: $17.87 |
| 16 |
67-4070 |
SLIDING SHAFT ASSEMBLY Price: $206.32 |
| 17 |
67-4280 |
DISCONTINUED Price: Call Us |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532439645. Price: $14.99 |
| 18 |
67-4060 |
LEVER Price: $145.19 |
| 19 |
67-4050 |
SHAFT Price: $30.29 |
| 20 |
532424341 |
CONTROL.THROTTLE.PRO. Price: $34.99 |
| 20 |
67-5040 |
DISCONTINUED Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
67-4090 |
LEVER Price: $52.49 |
| 22 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 22 |
70-8720 |
TIE ROD SPRING Price: $9.09 |
| 23 |
107-1581 |
TIE ROD ASM This part replaces 67-4030. Price: $82.44 |
| 24 |
107-1581 |
TIE ROD ASM This part replaces 67-4080. Price: $82.44 |
| 25 |
75-4990 |
GOVERNOR SPRING Price: $7.67 |
| 26 |
67-4210 |
TORQUE SPRING CASE Price: $22.42 |
| 27 |
67-4230 |
STOPPER Price: $25.34 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
67-4190 |
DISCONTINUED Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
67-4220 |
DISCONTINUED Price: Call Us |
| 30 |
67-4200 |
SPECIAL NUT Price: $5.71 |
| 31 |
67-4180 |
DISCONTINUED Price: Call Us |
| 32 |
43-2820 |
SEALING CAP Price: $11.21 |
| 33 |
42-9420 |
DISCONTINUED Price: Call Us |
| 34 |
67-4290 |
NUT Price: $0.91 |
| 35 |
67-4120 |
PIN Price: $1.25 |
| 37 |
42-8690 |
SEAL METAL MK99200001 Price: $3.26 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
42-8700 |
WIRE Price: $6.33 |
| 40 |
67-4150 |
STOP LEVER Price: $18.57 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 41 |
94-3827 |
SPRING Price: $25.25 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532178151 |
GASKET Price: $4.99 |
| 85 |
581636201 |
BOLT.HEX.7/16-20X3.0XGR5 Price: $4.99 |
| 86 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
