| Ref | Part Number | Description |
|---|
| 1 |
137-6113 |
LONG REAR ROLLER ASM (3IN DIA)(22IN) This part replaces 114-5415. Price: $383.80 |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 6 |
3230-7 |
BOLT-CARR Price: $0.88 |
| 7 |
114-5400 |
PLASTIC WIEHLE ROLLER ASM Price: $477.85 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
584908001 |
KEEPER BELT ENGINE This part replaces 532194320. Price: $2.99 |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 11 |
3231-4 |
SCREW-CARR Price: $3.59 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $229.99 |
| 12 |
140-5690 |
BRACKET-RM FRONT HOC This part replaces 125-2796. Price: $20.85 |
| 12 |
532194343 |
PULLEY ENGINE Price: $44.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $99.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 18 |
584248701 |
CAP.ASSY.FUEL.3".N-EPA.BLK.428 This part replaces 532430218. Price: $7.99 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532401135 |
LINE.FUEL.64"REAR.EMIS Price: $19.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532159955 |
RP.EXHAUST.TUBE.LH.BS/TWIN Price: $27.99 |
| 71 |
532160589 |
RP.EXHAUST.TUBE.RH.BS/TWIN Price: $39.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
