| Ref | Part Number | Description |
|---|
| 1 |
95-7522 |
AXLE Price: $377.20 |
| 1 |
MA-M414X04871 |
SCREW-SET Not Available Price: |
| 2 |
99-7564 |
SEAL-OIL Price: $25.36 |
| 2 |
MA-M614X64971 |
BRACKET ASS'Y., FRONT Not Available Price: |
| 3 |
95-7544 |
CLIP Price: $4.04 |
| 3 |
MA-M863C05571 |
LEVER ASSEMBLY-STARTER Not Available This part replaces MA-M863C06171. Price: |
| 4 |
95-7523 |
SPACER Price: $26.89 |
| 4 |
MA-M389X11482 |
SPRING SET Not Available This part replaces MA-M389X11472. Price: |
| 5 |
99-7555 |
SHIM 0.3 Price: $3.29 |
| 5 |
99-7556 |
SHIM 0.2 Price: $3.29 |
| 5 |
99-7557 |
SHIM 0.5 Price: $3.37 |
| 5 |
MA-M640827771 |
Bracket Ass'y.,Center Price: Call Us |
| 6 |
95-7525 |
GEAR-BEVEL, 27 TOOTH Price: $333.09 |
| 6 |
MA-M372X00471 |
STARTER SOLENOID Not Available Price: |
| 7 |
99-7534 |
BEARING-BALL Price: $65.44 |
| 7 |
MA-M901X00371 |
STARTER THRU BOLT Not Available Price: |
| 8 |
532165619 |
ROD.SHIFT.FENDER.ADJ.LT.CRD Price: $19.99 |
| 8 |
95-7521 |
COVER-AXLE Price: $107.87 |
| 8 |
MA-M106X29871 |
ARMATURE ASSEMBLY Not Available Price: |
| 9 |
106-1071 |
O-RING This part replaces 99-7538. Price: $18.43 |
| 9 |
MA-S930P14612 |
BEARING-FRONT Not Available This part replaces MA-S930P16470. Price: |
| 10 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 10 |
93-7775 |
BEARING-BALL This part replaces 99-7561. Price: $127.75 |
| 10 |
MA-S930P29901 |
BEARING-RE Not Available Price: |
| 11 |
99-7539 |
CLIP Price: $11.07 |
| 11 |
MA-M357X85371 |
SHAFT ASSEMBLY-CLUTCH Not Available Price: |
| 12 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 12 |
MA-M605X30671 |
PINION SET-BENDIX Not Available Price: |
| 13 |
MA-M385X03771 |
STOPPER SET-PINION Not Available Price: |
| 14 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 14 |
MA-M231X01371 |
GEAR ASSEMBLY-PINION W Not Available Price: |
| 15 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 15 |
MA-M357T73171 |
SHAFT ASSEMBLY-PINION Not Available Price: |
| 16 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 16 |
MA-M231C01301 |
GEAR Not Available Price: |
| 17 |
MA-M212X11771 |
COVER SET Not Available Price: |
| 18 |
MA-MM502440 |
Yoke Ass'y. Price: $306.85 |
| 19 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 19 |
MA-ME700127 |
HOLDER ASSEMBLY,BRUSH Not Available Price: |
| 20 |
MA-M391C02501 |
SPRING-BRU Not Available Price: |
| 21 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 21 |
MA-M644B21201 |
BRACKET ASSEMBLY-REAR Not Available Price: |
| 22 |
532169498 |
ROD BRAKE HYDRO Price: $17.99 |
| 22 |
MA-M578D22801 |
PACKING Not Available Price: |
| 24 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 24 |
MA-M648X28271 |
BRUSH-STARTER Not Available This part replaces MA-M648C28271. Price: |
| 25 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $4.99 |
| 26 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 27 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 28 |
532145204 |
ROD BRAKE PARK LT Price: $3.12 |
| 29 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 30 |
532130807 |
BRACKET TRANSAXLE This part replaces 532174973. Price: $3.99 |
| 32 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 34 |
532155071 |
SHAFT, FOOT PEDAL Price: $19.99 |
| 35 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 36 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 37 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532124963. Price: $3.99 |
| 38 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 39 |
874760644 |
BOLT Price: $3.99 |
| 40 |
532124965 |
SPACER T Price: $3.99 |
| 41 |
532165838 |
KEEPER.BELT.IDLER.FLAT Price: $4.99 |
| 42 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 47 |
532139245 |
PULLEY IDLER This part replaces 532127783. Price: $32.99 |
| 48 |
532154407 |
BELLCRANK, CLUTCH Price: $5.99 |
| 49 |
531151801 |
SERVICE KIT RETAIN BELT RETAIN This part replaces 532123205. Price: $3.99 |
| 50 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 874760624. Price: $6.99 |
| 51 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 53 |
532199652 |
LINK.CLUTCH.7.66.2005 This part replaces 532105710. Price: $8.99 |
| 55 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 56 |
874760620 |
BOLT Price: $4.99 |
| 57 |
532140294 |
DRIVE BELT, LTH & YTH TRACTORS Price: $34.99 |
| 59 |
532169691 |
KEEPER, BELT CENTER Price: $17.99 |
| 61 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 62 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 63 |
532140186 |
PULLEY.ENG.CL.MECH.SLVR.LT/YT Price: $99.99 |
| 64 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 871170764. Price: $2.99 |
| 65 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 66 |
531151001 |
SERVICE KIT BELT KEEPER This part replaces 532154778. Price: $6.99 |
| 69 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 70 |
531165301 |
SERVICE KIT KEEPER BELT This part replaces 532134683. Price: $6.99 |
| 71 |
532169183 |
STRAP TORQUE LH HYDRO Price: $4.99 |
| 72 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 73 |
532169182 |
STRAP TORQUE RH HYDRO Price: $14.99 |
| 74 |
532137057 |
SPACER AXLE Price: $5.99 |
| 75 |
532121749 |
WASHER Price: $2.99 |
| 76 |
812000001 |
E-RING LT Price: $3.99 |
| 77 |
532123583 |
SQUARE KEY Price: $3.99 |
| 78 |
532121748 |
WASHER Price: $3.99 |
| 81 |
532165596 |
SHAFT ASM CROSS TAPERED Price: $32.99 |
| 82 |
532123782 |
SPRING,TORSION Price: $3.99 |
| 83 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 84 |
532169843 |
LINK TRANSAXLE Price: $5.99 |
| 89 |
532176940 |
CONSOLE, SHIFT Price: $4.59 |
| 95 |
532170201 |
CONTROL ASM. BYPASS HYDRO Price: $8.99 |
| 96 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 103 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 116 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 150 |
532165850 |
BUSHING.BELLCRANK.GRD.DR Price: $4.99 |
| 151 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 156 |
596218801 |
Washers This part replaces 532166002. Price: $1.99 |
| 158 |
532437458 |
BRACKET.SHIFT.MOUNT This part replaces 532165589. Price: $5.99 |
| 159 |
532444304 |
HUB.SHIFT This part replaces 532165494. Price: $5.99 |
| 161 |
872110407 |
BOLT.CARRIAGE.1/4-20 X 7/8 This part replaces 872140406. Price: $3.99 |
| 162 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 163 |
596230901 |
Screws This part replaces 874780416. Price: $2.99 |
| 164 |
819091010 |
Washer 5/8 x .281 x 10 Ga Price: $3.15 |
| 165 |
531149501 |
SERVICE KIT BRACKET BRACKET.PI This part replaces 532165623. Price: $4.99 |
| 166 |
532166880 |
SCREW Price: $4.99 |
| 168 |
532165492 |
BOLT.SHOULDER.5/16-18X Price: $8.99 |
| 169 |
532165580 |
PLATE.FASTENING.CROSS.SHAFT Price: $5.99 |
| 197 |
532169613 |
NYLINER SNAP 5/8" ID Price: $4.99 |
| 198 |
532169593 |
WASHER.NYL.7/8IDX.105"HYD CR Price: $9.99 |
| 199 |
596231101 |
BOLT.5/16-18X.910 ST CLR ZINC This part replaces 532169612. Price: $3.99 |
| 200 |
595901501 |
Bolts This part replaces 872140508. Price: $3.99 |
| 202 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
