| Ref | Part Number | Description |
|---|
| 1 |
109-4695 |
KIT,HANDLE W/DECALS METRO This part replaces 109-4682-03. Price: $491.99 |
| 2 |
104-9838 |
GRIP-FOAM Price: $5.39 |
| 3 |
137-9508 |
LATCH-LH THUMB,W/GRIP Price: $25.99 |
| 5 |
1-302006 |
DRIVE LEVER ASM Price: $53.99 |
| 6 |
1-303021 |
GRIP-LEVER, DRIVE Price: $1.39 |
| 7 |
137-9507 |
LATCH-RH THUMB,W/GRIP Price: $25.99 |
| 8 |
1-303435 |
WASHER-SPRING Price: $1.39 |
| 9 |
1-323359 |
LINKAGE-WHEEL, DRIVE Price: $20.99 |
| 10 |
3296-42 |
NUT-LOCK, NI Price: $0.39 |
| 11 |
321-18 |
SCREW-HH Price: $1.89 |
| 12 |
116-2426 |
CONTROL, THROTTLE Price: $43.99 |
| 13 |
103-1797-01 |
BRACKET-CABLE, CHOKE Price: $8.29 |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 16 |
1-807513 |
BOLT-CARR Price: $2.29 |
| 17 |
1-806003 |
PIN-COTTER Price: $1.39 |
| 18 |
1-808250 |
PIN-LEVER, DRIVE Price: $2.29 |
| 19 |
1-803001 |
NUT-PUSH Price: $1.19 |
| 20 |
1-806340 |
PIN-ROLL Price: $4.79 |
| 21 |
1-323549 |
SPACER Price: $12.99 |
| 24 |
323-6 |
SCREW-HH Price: $2.29 |
| 25 |
1-303365 |
BUSHING-NYLON Price: $4.79 |
| 26 |
1-322192-03 |
WLD,ROD OPC Price: $40.99 |
| 27 |
1-303363 |
SPRING-EXTENSION Price: $6.09 |
| 28 |
103-1796 |
CABLE-CHOKE Price: $47.99 |
| 29 |
1-303088 |
CLIP-CABLE Price: $2.29 |
| 30 |
1-303160 |
SPRING-COMPRESSION Price: $6.09 |
| 31 |
1-323298 |
LINKAGE-BLADE, UPPER Price: $86.99 |
| 32 |
116-6331 |
LEVER ASM Price: $52.99 |
| 33 |
1-303020 |
GRIP-LEVER Price: $2.39 |
| 34 |
3256-4 |
WASHER-FLAT Price: $1.49 |
| 35 |
323-10 |
SCREW-HH Price: $0.69 |
| 36 |
3290-378 |
TIE-CABLE This part replaces 1-303335. Price: $0.79 |
| 37 |
1-808286 |
PIN-CLEVIS Price: $4.79 |
| 38 |
32128-33 |
NUT-HF Price: $0.69 |
| 39 |
321-3 |
SCREW-HH Price: $1.19 |
| 40 |
104-8301 |
NUT-HF, NI Price: $1.19 |
| 42 |
126-6877 |
DECAL, EXMARK LOGO Price: $6.59 |
| 43 |
116-7878 |
DECAL-NEUTRAL BRAKE Price: $17.99 |
| 44 |
106-2733 |
DECAL-THROTTLE Price: $9.99 |
