| Ref | Part Number | Description |
|---|
| 0 |
640082 |
CARBURETOR Price: Call Us |
| 1 |
137-6110 |
TUBE ROLLER 3.0IN DIA X 24.5IN This part replaces 114-5413-03. Price: $273.64 |
| 1 |
31834 |
SHAFT & LEV Price: $6.54 |
| 1 |
530016153 |
Screw Price: $1.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
573992801 |
KIT MODULE & FLYWHEEL This part replaces 530039232. Price: $39.99 |
| 2 |
631767 |
SPRING Price: $1.25 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
530016432 |
Screw Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
530058661 |
Strap-Ground Price: $1.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
530055698 |
Reflector-Tape Price: $1.99 |
| 6 |
640070 |
SHUTTER Price: $1.25 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
530016080 |
Screw Price: $1.99 |
| 9 |
530057891 |
Lever-Ignition Switch Price: $4.99 |
| 10 |
530057908 |
Spring-Ignition Switch Price: $2.99 |
| 10 |
632373 |
CHOKE SHAFT Price: $2.60 |
| 11 |
530059399 |
Knob-Choke Price: $1.99 |
| 12 |
530059001 |
Cover-Air Filter Price: $3.99 |
| 13 |
530057869 |
Filter-Air Price: $1.99 |
| 14 |
530016425 |
Screw Price: $1.99 |
| 14 |
640111 |
SHUTTER Price: $1.20 |
| 15 |
530150029 |
Housing-Air Filter w/cable Price: $4.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
545070601 |
Carburetor Zama W-26 This part replaces 530035590. Price: $27.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 18 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 18 |
630766 |
SPRING Price: $1.25 |
| 20 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 20 |
640018 |
FUEL JET Price: $6.16 |
| 20A |
640053 |
CAP Price: $0.81 |
| 21 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 23 |
530058660 |
Clip-High Tension Lead Price: $1.99 |
| 25 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 25 |
631951 |
FLOAT BOWL Price: $12.35 |
| 26 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 27 |
530071886 |
Kit-Spark Arrestor Price: $9.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 28 |
632816 |
FLOAT This part replaces 632802. Price: $5.90 |
| 29 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $49.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
530016417 |
Bolt Price: $1.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
27136A |
DRAIN ASSY Price: $5.96 |
| 32 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 33 |
27554 |
GASKET Price: $1.05 |
| 33 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 35 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 36 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 36 |
632735 |
NOZZLE Price: $4.95 |
| 37 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 37 |
632547 |
O RING Price: $1.49 |
| 38 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 39 |
530016426 |
Screw Price: $1.99 |
| 40 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 40 |
640089 |
NUT Price: $5.16 |
| 41 |
530057926 |
Tube-Intake Price: $1.99 |
| 42 |
530016101 |
Nut-Carb. Price: $1.99 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 44 |
530031163 |
Bar Wrench This part replaces 530031135. Price: $4.99 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 50 |
114-5430 |
ROLLER REBUILD KIT Price: $99.53 |
