| Ref | Part Number | Description |
|---|
| 1 |
94-4028 |
ROLLER-NEEDLE Price: $20.77 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 532445962. Price: $44.99 |
| 2 |
94-3939 |
SEAL-LIP Price: $52.94 |
| 3 |
94-3962 |
RING-RETAINING Price: $5.80 |
| 4 |
104-0168 |
BALL SWITCH KIT This part replaces 95-7034. Price: $87.16 |
| 5 |
94-4059 |
O-RING Price: $6.82 |
| 6 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 7 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 8 |
94-3945 |
RING-RETAINING Price: $2.64 |
| 9 |
532408667 |
KEEPER BELT ENGINE Price: $9.99 |
| 9 |
95-7037 |
SCREW Price: $5.85 |
| 10 |
94-4063 |
COVER-SERVO Price: $217.04 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 11 |
95-7040 |
GASKET-COVER, SERVO Price: $17.69 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 12 |
94-4070 |
PISTON-CONTROL Price: $220.76 |
| 14 |
94-4009 |
SCREW Price: $5.80 |
| 17 |
94-3936 |
NUT-LOCK, HEX Price: $3.00 |
| 18 |
95-7039 |
GASKET-HOUSING, CONTROL Price: $46.91 |
| 19 |
94-4065 |
COVER-CONTROL Price: $273.58 |
| 20 |
33106-035 |
SCREW-HHF This part replaces 94-4007. Price: $8.35 |
| 21 |
583533301 |
SCREW.#10X.750 (2 2) This part replaces 532438562. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
94-4069 |
SCREW Price: $12.84 |
| 25 |
94-4072 |
VALVE-SOLENOID Price: $1,287.08 |
| 26 |
94-4075 |
ELBOW Price: $115.78 |
| 27 |
94-4074 |
DISCONTINUED Price: Call Us |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 28 |
94-4076 |
HOSE ASM Price: $145.16 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
69-3450 |
PIN Price: $3.33 |
| 33 |
94-4026 |
DISCONTINUED Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
581636201 |
BOLT.HEX.7/16-20X3.0XGR5 Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 109 |
532414114 |
CANNISTER, CARBON Price: $54.99 |
| 110 |
532414118 |
VALVE.ASM.ANTI-SLOSH Price: $19.99 |
| 111 |
587044580 |
Hoses This part replaces 532414119. Price: $9.99 |
| 113 |
597791601 |
VALVES This part replaces 532414127. Price: $9.99 |
| 116 |
539132624 |
KNOB - SHIFT Price: $6.99 |
| 117 |
532420828 |
VALVE FUEL RESERVE Price: $27.99 |
