| Ref | Part Number | Description |
|---|
| 1 |
106160X |
O-RING TI Price: Call Us |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 3 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 4 |
74930572 |
BOLT TI Price: Call Us |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
1572H |
SUB= 2882J Price: Call Us |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
110111X |
LEVER ASM CRT Price: Call Us |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 7 |
72110404 |
BOLT Price: Call Us |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 8 |
8700J |
PANEL TI Price: Call Us |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 9 |
86777 |
SUB= 750097 Price: Call Us |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 10 |
9484R |
CONDIUT CLIP T Price: Call Us |
| 11 |
10040400 |
LOCKWASHER Price: Call Us |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 12 |
73220400 |
SUB= 50675 Price: Call Us |
| 13 |
23230506 |
SET SCREW Price: Call Us |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 14 |
8382J |
SPACER TI Price: Call Us |
| 15 |
19111116 |
WASHER Price: Call Us |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 17 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 18 |
8381J |
SPACER TI Price: Call Us |
| 19 |
2649M |
KEY T Price: Call Us |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
4914H |
KEY TI Price: Call Us |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
139155 |
SPACER.SPLIT Price: Call Us |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 22 |
104214X |
NUT TI Price: Call Us |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
5015J |
TIRE TI Price: Call Us |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 24 |
4929H |
RIVET.PAN HD.1.75 Price: Call Us |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 25 |
4921H |
SPRING.RETAINER Price: Call Us |
| 26 |
102818X505 |
GUARD BELT RED Price: Call Us |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 27 |
138399 |
BELT.DRIVE Price: Call Us |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 28 |
104680X |
SUB= 4371J Price: Call Us |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
12000032 |
KLIP RING Price: Call Us |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
105611X |
SUB= 918105611X Price: Call Us |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
74770844 |
BOLT1/2-20UNF2.75 Price: Call Us |
| 32 |
139401 |
SHAFT.IDLER Price: Call Us |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 33 |
19171616 |
WASHER Price: Call Us |
| 34 |
4368J |
SHEAVE CRT Price: Call Us |
| 138417 |
RIM.16X4X8.WHT |
Price: Call Us 138417 |
