| Ref | Part Number | Description |
|---|
| 1 |
100-8511 |
TUBE-BRAKE, REAR (LH) Price: $55.32 |
| 2 |
2412-149 |
CLAMP-R Price: $0.68 |
| 2 |
532069180 |
Locknut #10-24 Price: $2.69 |
| 3 |
32128-33 |
NUT-HF Price: $0.25 |
| 3 |
532127533 |
Screen, Cover Price: $11.99 |
| 4 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 5 |
2412-74 |
R-CLAMP Price: $2.37 |
| 5 |
532128598 |
Chute, Upper Price: $58.99 |
| 6 |
818021008 |
Screw, Special Price: $3.99 |
| 6 |
98346 |
FITTING-TEE Price: $20.10 |
| 7 |
100-8510 |
TUBE-BRAKE, REAR (RH) Price: $55.35 |
| 7 |
532140572 |
Indicator, Dump Bag Price: $4.99 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 9 |
100-8509 |
BRAKE TUBE ASM Price: $110.26 |
| 9 |
819061216 |
Washer 3/16 x 3/4 Price: $2.69 |
| 10 |
100-8506 |
DISCONTINUED Price: Call Us |
| 10 |
532007206 |
Spacer, Split Price: $3.99 |
| 11 |
100-8508 |
DISCONTINUED Price: Call Us |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 12 |
810071000 |
Washer, lock Price: $2.99 |
| 12 |
87-3580 |
CLIP-RETAINER Price: $2.48 |
| 13 |
532109808 |
Latch, Chute Price: $2.69 |
| 13 |
87-3560 |
TEE Price: $14.59 |
| 14 |
100-8507 |
TUBE-BRAKE, FRONT (LH) Price: $48.64 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 15 |
100-8420 |
HOSE-BRAKE, FRONT Price: $118.26 |
| 15 |
874780516 |
BOLT FIN HEX 5/16-18 X 1 This part replaces 874930516. Price: $3.99 |
| 16 |
100-8467 |
HOSE-BRAKE, FRONT (LH) Price: $148.02 |
| 17 |
2412-134 |
CLAMP-R Price: $5.79 |
| 17 |
532160793 |
Latch Hook Asm. This part replaces 532130758. Price: $7.99 |
| 18 |
532128599 |
Chute, Lower Price: $86.99 |
| 19 |
532133841 |
Nut, Acorn 5/16-18 Price: $2.99 |
| 20 |
871081010 |
Screw #10-24 x 5/8 Price: $3.49 |
| 21 |
532132796 |
Spring, Cover L.H. (black) Price: $2.99 |
| 22 |
532133235 |
Spacer, Cover Price: $3.99 |
| 23 |
532132983 |
Spring, Cover R.H. (gray) Price: $2.99 |
| 24 |
532127720 |
Post, Support Price: $13.00 |
| 25 |
873800500 |
Locknut 5/16 x 18 Price: $2.69 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 27 |
872110506 |
Bolt, Carriage 5/16-18 x 3/4 Price: $3.99 |
| 28 |
532170053 |
Bracket, Mounting Price: $9.99 |
| 29 |
532170165 |
Shoulder Bolt, Self-Tapping Price: $2.99 |
| 30 |
532131137 |
Pin, Support Post Price: $6.99 |
| 31 |
532174083 |
Cap, Tubing End Price: $3.99 |
| 32 |
532126919 |
Bagger, Frame Price: $59.99 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 34 |
532127534 |
Gasket, Cover Price: $8.99 |
| 35 |
532183286 |
Container, Top Price: $17.99 |
| 36 |
532129586 |
Container, Bottom Price: $62.99 |
| 38 |
532130895 |
Latch Handle, Cover Price: $3.99 |
| 39 |
532155042 |
Strip, Reinforcement Price: $11.99 |
| 41 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 42 |
532137031 |
U-Bolt Price: $2.42 |
| 43 |
532123635 |
Weight, Wheel Price: $53.79 |
