| Ref | Part Number | Description |
|---|
| 1 |
532439699 |
SEAT.XH130.MS498.G.HUSQ.NONTEX This part replaces 532140839. Price: $179.99 |
| 1 |
95-7539 |
CASE-GEAR, BEVEL Price: $212.14 |
| 2 |
532140551 |
SUB= 140551 Price: $3.99 |
| 2 |
99-7594 |
SEAL-OIL Price: $5.99 |
| 3 |
874780616 |
Bolt Fin Hex 3/8-16 Unc x 1 Gr. 5 This part replaces 874760616. Price: $3.99 |
| 3 |
99-7595 |
BEARING-NEEDLE Price: $118.02 |
| 4 |
104-2376 |
KNUCKLE ASM This part replaces 95-7511. Price: $68.43 |
| 4 |
819131610 |
WASHER 13/32 X 1 X 10 GA Price: $3.99 |
| 5 |
104-2376 |
KNUCKLE ASM This part replaces 95-7510. Price: $68.43 |
| 5 |
532145006 |
SUB= 145006 Price: $2.99 |
| 6 |
104-2374 |
BOLT This part replaces 99-7596. Price: $6.33 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
100-3746 |
AXLE CASE SUPPORT ASM, LH Price: $204.04 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 8 |
100-3748 |
AXLE CASE SUPPORT ASM, RH Price: $204.04 |
| 8 |
817000616 |
SCREW Price: $3.99 |
| 9 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 10 |
532195530 |
PAN, SEAT This part replaces 532155925. Price: $14.99 |
| 10 |
95-7547 |
SHIM 0.1 Price: $2.53 |
| 10 |
95-7548 |
SHIM 0.2 Price: $3.52 |
| 10 |
95-7549 |
SHIM 0.3 Price: $3.82 |
| 11 |
532166369 |
KNOB SEAT Price: $4.99 |
| 11 |
99-7597 |
PIN-DOWEL Price: $3.74 |
| 12 |
532174648 |
Bracket Mounting Switch This part replaces 532121246. Price: $4.99 |
| 12 |
99-7598 |
BOLT Price: $7.67 |
| 13 |
100-3736 |
BOLT Price: $0.85 |
| 13 |
532121248 |
SUB= 121248X Price: $3.99 |
| 14 |
100-3737 |
STUD Price: $1.56 |
| 14 |
872050412 |
BOLT, CARRIAGE 1/4-20 X 1-1/2 Price: $3.99 |
| 15 |
532134300 |
SUB= 134300 Price: $3.99 |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
532121250 |
SUB= 121250X Price: $3.99 |
| 16 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 21 |
532171852 |
BOLT Price: $3.99 |
| 22 |
873800500 |
LOCKNUT Price: $2.69 |
| 24 |
819171912 |
WASHER 17/32 X 1-3/16 X 12 GA Price: $3.99 |
