| Ref | Part Number | Description |
|---|
| 2 |
631-05024 |
DECK BELT COVER ASSEMBLY Price: $25.19 |
| 3 |
647-05028 |
IDLER GUIDE ROD ASSEMBLY Price: $16.78 |
| 4 |
983-05034 |
BRAKE PTO BRACKET ASSEMBLY Price: $14.87 |
| 6 |
710-0347 |
HEX SCREW 3/8-16 x 1.75 GR5 Price: $4.39 |
| 7 |
710-0514 |
SCREW 3/8-16 x 1 GR5 Price: $3.78 |
| 8 |
710-0599 |
SCREW 1/4-20 X.500 Price: $3.86 |
| 9 |
710-06322 |
SCREW 5/16-18 x .875 Price: $4.55 |
| 10 |
710-0805A |
SCREW 5/16-18 x 1.5 LG Price: $3.75 |
| 11 |
710-1026 |
SCREW 1/4-20 x 1.750 Price: $5.94 |
| 12 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 13 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 14 |
712-04065 |
NUT Price: $3.68 |
| 15 |
712-05134 |
FLANGE NUT 5/8-18 Price: $5.52 |
| 16 |
732-05045 |
TORSION SPRING PTO Price: $3.70 |
| 17 |
732-05046 |
TORSION SPRING BRAKE Price: $3.70 |
| 18 |
732-0583 |
SPRING Price: $10.65 |
| 19 |
736-3040 |
HUB CAP WASHER .406 x 1.92 x .060 Price: $5.52 |
| 20 |
736-3078 |
FLAT WASHER 344X1.00 Price: $3.95 |
| 22 |
938-0347 |
SHOULDER SPACER Price: $8.93 |
| 23 |
738-04184A |
SHOULDER SCREW Price: $5.99 |
| 24 |
738-05021 |
DOUBLE SHOULDER SPACER Price: $3.70 |
| 25 |
738-05022 |
DOUBLE SHOULDER SPACER Price: $3.74 |
| 26 |
946-04802A |
PTO CABLE Price: $33.53 |
| 27 |
747-06126A |
DECK BELT KEEPER Price: $15.13 |
| 28 |
750-04456 |
SPACER:.260 x .372 x 1.420 Price: $6.20 |
| 29 |
954-05001 |
V-BELT A SEC 43.5 Price: $42.39 |
| 30 |
756-04224 |
FLAT IDLER PULLEY 2.75 OD Price: $24.80 |
| 31 |
783-08047A |
SPINDLE SUPPORT BRACKET Price: $13.83 |
| 32 |
783-08128 |
IDLER BRACKET FLOATING LOWER Price: $14.87 |
