| Ref | Part Number | Description |
|---|
| 2 |
04915400 |
CLUTCH, ELECTRIC Price: $367.45 |
| 3 |
06604300 |
KEY-SQ .25 X 1.50 X .25 SAE Price: $3.95 |
| 4 |
01577851 |
CLUTCH STOP Price: $29.95 |
| 5 |
00363200 |
EXTENSION, CRANK SHAFT This part replaces 01602500. Price: $254.95 |
| 6 |
07241400 |
BELT,HA WRAPPED Price: $46.95 |
| 7 |
01589600 |
IDLER-TRANSAXLE Price: Call Us |
| 8 |
05516400 |
BSHG-SLV .500X.750X1.560 Price: $5.45 |
| 9 |
07327100 |
PULLEY, IDLER 4.00 Price: $33.95 |
| 10 |
01591000 |
BSHG-SPCR .41X75X.69 Price: $8.95 |
| 11 |
08300728 |
SPRING- EXTENSION This part replaces 08336000. Price: $24.95 |
| 12 |
05901821 |
BLT, HEX .44-20X4.50 G8 ZCC This part replaces 05966700. Price: $6.45 |
| 13 |
06300121 |
WSHR, LK-REG .438X.109 ZCC This part replaces 06309300. Price: $2.45 |
| 14 |
06401111 |
WSHR, FLT .469X2.00X.250 ZCC This part replaces 06443600. Price: $6.95 |
| 15 |
05901712 |
BLT, HEX .50-13X2.50 G5 ZCC This part replaces 05966600. Price: $3.45 |
| 16 |
06500907 |
NUT-LK-TOP-FLG .500-13 GF ZCC This part replaces 06543600. Price: $1.45 |
| 17 |
06200301 |
BLT,RHSN .38-16X2.25 G5 ZCC This part replaces 06226800. Price: $3.95 |
| 18 |
06200417 |
BLT, RHSN .38-16X1.75 G5 ZCC This part replaces 06223800. Price: $3.95 |
| 21 |
06500726 |
NUT,NYL-FLG .38-16 GF ZCC This part replaces 06544500. Price: $1.45 |
| 22 |
05901710 |
BLT, HEX .31-18X1.50 G5 ZCC This part replaces 05952400. Price: $1.45 |
| 25 |
01590900 |
TUBE, OIL DRAIN 8" CLEAR VINYL Price: $5.45 |
| 26 |
07517300 |
CABLE TIE LG 5-1/2 This part replaces 036313. Price: $2.95 |
| 27 |
07067800 |
VALVE, OIL DRAIN Price: $31.45 |
| 29 |
05901804 |
BLT, HEX .31-18X1.75 G5 ZCC This part replaces 05957400. Price: $2.95 |
