CLUTCH, OIL PUMP & SPURS
Parts (61)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 108-6715 | GAUGE BAR ASM Price: $148.12 |
| 1 | 507475976 | Clutch Ass'y. (incl. 2-4) Price: $59.99 |
| 2 | 29-9100 | BRUSH AND HANDLE ASM Price: $58.15 |
| 2 | 507433133 | Clutch Driver Price: $17.99 |
| 3 | 507433102 | Clutch Shoe Price: $7.99 |
| 4 | 115-0803 | ROLLER REBUILD TOOL KIT Price: $122.41 |
| 4 | 507431200 | Clutch Spring Price: $2.99 |
| 5 | 507430800 | Nut Price: $1.99 |
| 6 | 507433036 | Strut Nut Price: $1.99 |
| 7 | 507475081 | Clutch Drum & Bearing Price: $3.33 |
| 8 | 530032049 | Bearing Price: $8.99 |
| 9 | 507429957 | Rim Segment 404 7T Price: $8.99 |
| 9 | 952004746 | Rim Segment 3/8 7T Price: Call Us |
| 10 | 507430848 | Thrust Washer Price: $1.99 |
| 11 | 5074765721 | Brake Ass'y. (lncl. 13-31) Price: Call Us |
| 12 | 5074762761 | Clutch Cover & Tensioner Price: Call Us |
| 13 | 507425672 | Pin Price: $3.99 |
| 14 | 507431636 | Retaining Ring Price: $0.24 |
| 15 | 507432613 | Screw Price: $2.99 |
| 16 | 507433109 | Outer Guide Plate Price: $6.99 |
| 17 | 507429266 | Terminal Screw Price: $1.99 |
| 18 | 507433185 | Spring Price: $14.99 |
| 19 | 507476284 | Cam/Band Ass'y. Price: $16.24 |
| 20 | 507431038 | Locking Plate Price: $1.99 |
| 21 | 50747648618 | Kickback Guard Ass'y. Price: Call Us |
| 22 | 507476583 | Cover Ass'y. Price: $2.99 |
| 23 | 507431036 | Bolt Price: $4.99 |
| 24 | 507431716 | Screw Price: $1.99 |
| 25 | 507430930 | Washer Price: $2.99 |
| 26 | 507433529 | Bushing Price: $4.99 |
| 27 | 507433532 | Washer Price: $1.99 |
| 28 | 507430878 | Washer Price: $1.99 |
| 29 | 507431675 | Screw Price: $0.99 |
| 30 | 507431673 | Screw Price: $0.99 |
| 31 | 530015515 | Nut Price: $1.99 |
| 32 | 507432686 | Inner Guide Plate Price: $2.99 |
| 33 | 507476072 | Bucking Spur (Incl.screws, washers, 2 spurs) Northeast Style Price: $1.60 |
| 33 | 507476079 | Bucking Spur (Incl.screws, washers, 2 spurs) Smaller Style Price: $3.33 |
| 34 | 507433712 | Side Decal Price: $3.33 |
| 35 | 507430197 | Shock Absorber Price: $4.99 |
| 36 | 507431642 | Screw Price: $1.99 |
| 37 | 507433538 | Dirt Shield Price: $4.99 |
| 38 | 507431669 | Screw Price: $1.99 |
| 39 | 507433539 | Gasket Price: $1.99 |
| 40 | 507430231 | Wire Worm Price: $3.99 |
| 41 | 507428746 | Seal Price: $3.99 |
| 42 | 507476505 | Oil Pump Ass'y. w/ Manual Overide (Incl. 43, 44, 46,47,49-52) Price: $64.99 |
| 43 | 507430640 | Inlet Tube Price: $0.68 |
| 44 | 507476504 | Oil Pump Body Price: $54.99 |
| 45 | 507431221 | Plunger Spring Price: $5.12 |
| 46 | 507430880 | Oil Pump Gear Price: $0.72 |
| 47 | 507474932 | Plunger Ass'y. Price: $0.28 |
| 48 | 507431699 | Roll Pin Price: $1.99 |
| 49 | 507433242 | Adj. Screw Price: $3.33 |
| 50 | 507431359 | O-Ring Price: $1.99 |
| 51 | 507430229 | Oil Pump Seal Price: $0.99 |
| 52 | 507475499 | Oil Pump Ass'y. (Incl. 54-58) Price: $49.52 |
| 53 | 507432317 | Sleeve Price: $1.24 |
| 54 | 507432303 | Nut Price: $1.99 |
| 55 | 507476369 | Manual Oil Pump Price: $32.99 |
| 56 | 501606801 | Speed Clip Price: $2.99 |
