| Ref | Part Number | Description |
|---|
| 1 |
545036401 |
NOSE CONE BH LEFT Price: $3.99 |
| 2 |
545036501 |
NOSE CONE BH RIGHT Price: $3.99 |
| 3 |
530016448 |
SCREW Price: $2.99 |
| 3 |
99-8344 |
CYLINDER HEAD ASM Price: $1,792.58 |
| 4 |
530016449 |
SCREW M4 X 1.75 PT 16MM Price: $3.99 |
| 4 |
98-9479 |
BOLT-HEAD, CYLINDER Price: $14.42 |
| 5 |
107-9066 |
GUIDE-VALVE, INLET This part replaces 98-9499. Price: $12.65 |
| 5 |
537172802 |
HANDLE Price: $6.99 |
| 6 |
107-9067 |
GUIDE-VALVE, EXHAUST This part replaces 98-9500. Price: $13.17 |
| 6 |
503200245 |
SCREW Price: $3.99 |
| 7 |
98-9389 |
CAP-SEALING Price: $5.22 |
| 8 |
530015940 |
SCREW Price: $2.99 |
| 9 |
105-3705 |
CAP-SEALING This part replaces 98-9395. Price: $6.44 |
| 10 |
502199503 |
HANDLE Price: $29.99 |
| 10 |
98-9613 |
GASKET-HEAD, CYLINDER Price: $177.34 |
| 11 |
731231401 |
NUT Price: $1.99 |
| 11 |
98-9687 |
PLUG This part replaces 98-7540. Price: $2.86 |
| 12 |
537172901 |
BRACKET Price: $4.99 |
| 12 |
98-7509 |
O-RING Price: $4.31 |
| 13 |
502211201 |
GROMMET Price: $3.99 |
| 13 |
98-9647 |
BOLT-HEAD, CYLINDER Price: $15.60 |
| 16 |
530015814 |
SCREW Price: $0.17 |
| 17 |
530058563 |
CLAMP BRACKET Price: $2.99 |
| 18 |
545058501 |
CLAMP Price: $9.99 |
| 19 |
537419001 |
STOP BUTTON Price: $7.99 |
| 20 |
537160703 |
STARTER THROTTLE LOCK This part replaces 537160701. Price: $4.99 |
| 21 |
537174301 |
SPRING Price: $3.99 |
| 22 |
503221013 |
NUT Price: $3.99 |
| 23 |
506497701 |
THROTTLE CONTROL This part replaces 537160601. Price: $6.99 |
| 24 |
537160203 |
HANDLE Price: $17.99 |
| 25 |
545125801 |
ASSY CABLE WIRE HARNESS Price: $27.99 |
| 26 |
537174201 |
SPRING Price: $4.99 |
| 27 |
506497701 |
THROTTLE CONTROL This part replaces 537160801. Price: $6.99 |
| 28 |
503216618 |
SCREW Price: $3.99 |
| 29 |
503200782 |
SCREW IHSCFM This part replaces 503200735. Price: $3.99 |
| 30 |
537160301 |
HANDLE Price: $14.99 |
| 32 |
596296801 |
HUS STANDARD HARNESS This part replaces 537216302. Price: $29.99 |
| 34 |
530052286 |
Limiter - Line Price: $0.68 |
| 35 |
530015814 |
SCREW Price: $0.17 |
| 36 |
596278001 |
HUS 10" GRASSBLADE 255-4T 1" This part replaces 537149604. Price: $22.99 |
| 37 |
503890101 |
SUPPORTING CUP Price: $14.99 |
| 38 |
537285601 |
SUPPORT FLANGE Price: $9.99 |
| 39 |
503856301 |
GEARHEAD NUT - BRUSHCUTTER Price: $5.99 |
| 40 |
530016014 |
SCREW - CARB. ADAPTOR Price: $2.99 |
| 41 |
545003902 |
SCREW Price: $2.99 |
| 42 |
537234901 |
DRIVE DISC Price: $19.99 |
| 43 |
530015771 |
SCREW 1/4-20 X 7/8 (TAP Price: $3.99 |
| 44 |
530057554 |
BRACKET SHIELD STRAIGHT SHAFT Price: $4.99 |
| 45 |
502285901 |
LOCKING PIN Price: $4.99 |
| 46 |
530096295 |
ASSY GEARBOX Price: $34.99 |
| 47 |
537338310 |
TRIMMER HEAD T25 This part replaces 537338302. Price: $27.99 |
