| Ref | Part Number | Description |
|---|
| 2 |
532199791 |
PULLEY MANDREL 5.0" Price: $22.99 |
| 3 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 4 |
531350601 |
PULLEY IDLER, BACKSIDE 3 INCH This part replaces 539110311. Price: $19.99 |
| 6 |
573970402 |
COVER, PULLEY, BLACK Price: $17.99 |
| 7 |
532400140 |
BELT KEEPER.MANDREL.38"COATED Price: $39.99 |
| 8 |
529311701 |
KEEPER, BELT, BLACK This part replaces 532420253. Price: $4.99 |
| 9 |
525851801 |
GUIDE, BELT Price: $11.99 |
| 10 |
585053902 |
ARM.IDLER.30".RZ.X431 Price: $6.99 |
| 11 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED Price: $14.99 |
| 12 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $29.99 |
| 13 |
581514302 |
SWIVEL TRUNION CLEAR ZINC This part replaces 581514301. Price: $4.99 |
| 14 |
532110485 |
BEARING Price: $11.99 |
| 15 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 16 |
581506902 |
Links This part replaces 532195740. Price: $9.99 |
| 17 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 18 |
525848801 |
SPACER .39 ID X 2.25 Price: $6.99 |
| 19 |
532193216 |
SPRING.BRAKE.RETURN.38" Price: $4.99 |
| 20 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 21 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 587253301. Price: $49.99 |
| 22 |
532417344 |
SHIELD.DEFLECT.MWR.30S.BLACK Price: $37.99 |
| 23 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 24 |
585054001 |
BELT DECK 99.60 EFL Price: $59.99 |
| 25 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 26 |
532416405 |
COUPLING.QUICK CONNECT Price: $8.99 |
| 27 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 28 |
596580601 |
Pins This part replaces 539976988. Price: $3.99 |
| 29 |
596273101 |
Pins This part replaces 539976989. Price: $2.99 |
| 30 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 31 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 32 |
539990701 |
BLT 3/8-16X1-3/4 WHIZLK ZN SP Price: $2.99 |
| 33 |
596241101 |
Bolts This part replaces 539113621. Price: $2.99 |
| 34 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 35 |
596564403 |
Screws This part replaces 874780632. Price: $3.99 |
| 36 |
525848601 |
RHSNB 3/8-16 X 4 GR5 ZD Price: $4.99 |
| 37 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 38 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 39 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 40 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 41 |
573975201 |
NUT, 7/16-20 HEX NYLOC ZC Price: $2.99 |
| 42 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 43 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 44 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 45 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 46 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 47 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
| 48 |
819171713 |
WASHER STEEL Price: $2.99 |
| 49 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 50 |
596433701 |
GSPW Washers This part replaces 819141614. Price: $2.99 |
| 51 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 52 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
