| Ref | Part Number | Description |
|---|
| 1 |
22-8330 |
PLUG Price: $64.59 |
| 1 |
532411423 |
KIT.LEVER.CONTROL.RH.AUGER This part replaces 532184110. Price: $22.99 |
| 2 |
237-42 |
O-RING Price: $2.78 |
| 2 |
532184109 |
LEVER, TRACTION DRIVE CONTROL Price: $9.99 |
| 3 |
22-8340 |
SPRING Price: $19.09 |
| 3 |
532179439 |
NUT, CAGE 1/4-20 Price: $2.99 |
| 4 |
22-8350 |
BALL Price: $12.28 |
| 4 |
532178888 |
BUSHING, FLANGE Price: $3.99 |
| 5 |
22-8370 |
SEAT-VALVE Price: $88.05 |
| 5 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 6 |
22-8360 |
PIN Price: $43.02 |
| 6 |
532199640 |
SCREW HEX This part replaces 532180402. Price: $3.99 |
| 7 |
121-9070 |
VALVE ASM This part replaces 43-1730. Price: $458.43 |
| 7 |
532178652 |
ROD.INTERLOCK Price: $9.99 |
| 8 |
22-8420 |
SPOOL Price: $437.22 |
| 8 |
532184003 |
TUBE ASSM, INTERLOCK Price: $13.99 |
| 9 |
22-8500 |
O-RING Price: $18.87 |
| 9 |
532178651 |
TUBE.WELDMENT.INTERLOCK.LH Price: $20.99 |
| 10 |
22-8380 |
RETAINER Price: $17.86 |
| 10 |
532178645 |
PANEL, CONTROL This part replaces 532184106. Price: $22.99 |
| 11 |
22-8410 |
SPRING Price: $17.61 |
| 11 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 12 |
23-3030 |
SPACER Price: $33.93 |
| 12 |
874780528 |
SCREW Price: $4.99 |
| 13 |
22-8480 |
RING-SNAP Price: $49.87 |
| 13 |
532436114 |
TUBE.HANDLE.LOOP.LH.BLACK This part replaces 532184107. Price: $54.99 |
| 14 |
532407857 |
TUBE.HANDLE.LOOP.RH.BLACK This part replaces 532184108. Price: $39.99 |
| 15 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 16 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 17 |
532178899 |
KNOB.HANDLE.3/8.TRI-POINT.BLAC Price: $4.99 |
| 18 |
580797701 |
ROD.IMPELLER.CONTROL.SNOW This part replaces 532179093. Price: $12.99 |
| 19 |
532179098 |
ROD.TRACTION.CONTROL Price: $12.99 |
| 20 |
532180428 |
ROD, END CONTROL Price: $8.99 |
| 21 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 22 |
872120618 |
BOLT 3/8-16 X 2-1/4 Price: $5.99 |
| 23 |
532184087 |
TUBE.LOWER.HANDLE.24.BLACK Price: $59.99 |
| 24 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 25 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 26 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 27 |
871210616 |
Screw, Hex Head 3/8-16 x 1 Price: $4.99 |
| 28 |
532180494 |
PANEL CLIP Price: $2.64 |
| 30 |
532183352 |
CONSOLE, HANDLE Price: $24.99 |
| 31 |
532175262 |
SCREW, HEX HD TAPPING #10-24 1 Price: $3.99 |
| 32 |
532750634 |
SCREW Price: $2.99 |
| 33 |
532184111 |
ARM.LATCH.INTERLOCK.YELLOW Price: $3.99 |
| 34 |
532183518 |
BOLT, SHOULDER Price: $2.99 |
| 35 |
873850400 |
This part replaces 532068038. Price: $2.51 |
| 36 |
532443215 |
SPRING.TORSION.LEVER This part replaces 532178831. Price: $3.99 |
