| Ref | Part Number | Description |
|---|
| 1 |
104-0402 |
TUBE-HYD Price: $147.93 |
| 2 |
340-70 |
NUT-LOCK Price: $2.10 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 4 |
104-0407 |
HOSE-HYD Price: $126.67 |
| 5 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 6 |
100-4891 |
HOSE-HYD Price: $161.55 |
| 7 |
104-0403 |
TUBE ASM Price: $145.25 |
| 8 |
340-71 |
FITTING-STRAIGHT, BULKHEAD Price: $20.74 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 10 |
112-9916 |
HYD CYLINDER ASM Price: $752.66 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 11 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 13 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 14 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 15 |
100-4879 |
HOSE-HYD Price: $272.03 |
| 15 |
532179115 |
TANK.FUEL.5.0 LEFT.FILL.YTGT Price: $89.99 |
| 16 |
115-3411 |
HOSE-HYD Price: $114.49 |
| 17 |
104-0401 |
TUBE ASM Price: $210.81 |
| 18 |
104-0400 |
TUBE ASM Price: $175.47 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 19 |
104-0404 |
TUBE ASM Price: $142.78 |
| 20 |
532178147 |
CONTROL.THROTTLE.COBRA.42"BLK. Price: $29.99 |
| 20 |
99-3641 |
CLAMP-TUBE Price: $5.90 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 22 |
321-11 |
SCREW-HH Price: $0.36 |
| 22 |
532175441 |
CHOKE CONTROL This part replaces 532178148. Price: $24.99 |
| 23 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 24 |
95-8990 |
SHAFT-PIVOT, REAR Price: $75.06 |
| 25 |
3220-9 |
NUT-JAM Price: $11.71 |
| 25 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 26 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 26 |
86-1480 |
WASHER Price: $4.82 |
| 27 |
136-3415 |
REAR LIFTARM ASM This part replaces 115-3473. Price: $685.84 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
3234-27 |
SCREW-HHF Price: $5.97 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
75-7730 |
WASHER-THRUST Price: $2.88 |
| 31 |
100-4944 |
SHAFT-PIVOT, CUTTING UNIT Price: $87.73 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
323-6 |
SCREW-HH Price: $0.66 |
| 33 |
323-4 |
SCREW-HH Price: $1.02 |
| 34 |
63-7400 |
WASHER-REBOUND Price: $1.70 |
| 35 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 36 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
121-3616-03 |
GUARD Price: $35.32 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 44 |
322-3 |
SCREW-HH Price: $0.79 |
| 45 |
32128-20 |
NUT-HF Price: $0.99 |
| 46 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 47 |
95-8575 |
PIN-CLEVIS Price: $15.31 |
| 49 |
3334-945 |
TIE-CABLE Price: $0.43 |
| 50 |
104-4229 |
REAR CARRIER FRAME ASM Price: $470.75 |
| 51 |
95-8936 |
STRIP-WEAR Price: $93.56 |
| 52 |
3269-18 |
RIVET-BLIND Price: $1.15 |
| 53 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 62 |
532176252 |
HEAT SHIELD Price: $5.59 |
| 70 |
532175767 |
TUBE.EXHAUST.KAWASAKI.RH Price: $54.99 |
| 71 |
532175766 |
TUBE EXHAUST LH Price: $48.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
