| Ref | Part Number | Description |
|---|
| 1 |
576370401 |
FENDER, RT, GRAY Price: $54.99 |
| 1 |
66-8120 |
PIPE-STAND Price: $36.87 |
| 2 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 2 |
539130374 |
FENDER, LT Price: $74.99 |
| 3 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 3 |
599306304 |
FUEL TANK, RZ, 2.25" NECK, 202 This part replaces 576369401. Price: $229.99 |
| 4 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 4 |
575018103 |
CAP 3.5IN SEALED This part replaces 575018101. Price: $27.99 |
| 5 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 5 |
539112734 |
THROTTLE CABLE Price: $29.99 |
| 6 |
532140401 |
KEY MLD GEN DELTA This part replaces 539107544. Price: $5.99 |
| 6 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 7 |
110-3257 |
HOSE-FUEL This part replaces 63-7630. Price: $17.26 |
| 7 |
532175566 |
IGNITION SWITCH This part replaces 539107541. Price: $22.99 |
| 8 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 539101768. Price: $24.99 |
| 8 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 9 |
2412-96 |
CLAMP-R Price: $3.46 |
| 9 |
539113792 |
SWITCH, BRAKE 3P Price: $14.99 |
| 10 |
32128-20 |
NUT-HF Price: $0.99 |
| 10 |
539101080 |
SWITCH, INTERLOCK Price: $14.99 |
| 11 |
539110305 |
PLATE.CONTROL.CONSOLE.BLACK Price: $27.99 |
| 11 |
70-8621 |
DIESEL FUEL CAP Price: $30.55 |
| 12 |
237-136 |
GROMMET Price: $3.52 |
| 12 |
579411601 |
BATTERY, 12 V 300 AMP DRY This part replaces 539102436. Price: $129.99 |
| 13 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 13 |
539131209 |
BATTERY TIE DOWN ASSEMBLY Price: $27.99 |
| 14 |
3256-67 |
WASHER Price: $0.49 |
| 14 |
510231302 |
BOX, BATTERY, BLACK Price: $89.99 |
| 15 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
539116400 |
TERMINAL COVER-SM Price: $2.99 |
| 16 |
321-5 |
SCREW-HH Price: $0.22 |
| 16 |
539102759 |
INSULATOR Price: $3.99 |
| 17 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 17 |
576618101 |
VALVE.FUEL.CHECK Price: $14.99 |
| 18 |
231-101 |
TIRE (23X8.5-12) 4-PLY TURF SAVER Price: $147.85 |
| 18 |
539916325 |
FUEL VALVE Price: $9.99 |
| 19 |
217-117 |
WHEEL Price: $164.56 |
| 19 |
539101714 |
SOLENOID Price: $22.99 |
| 20 |
23-7270 |
NUT-LUG Price: $10.37 |
| 20 |
539912222 |
HOSE CLAMP Price: $2.99 |
| 21 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 21 |
575436501 |
CLAMP, HOSE Price: $2.99 |
| 22 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 22 |
539105245 |
RUBBER GROMMET Price: $3.99 |
| 23 |
584648201 |
GROMMET.CHECK.FUEL This part replaces 576618201. Price: $3.99 |
| 24 |
532139277 |
STEM FUEL TANK This part replaces 539110432. Price: $6.99 |
| 25 |
27-4310-01 |
MASKED PIVOT PIN This part replaces 27-4310. Price: $31.42 |
| 25 |
539110457 |
LEFT HEADLIGHT LENS This part replaces 539110056. Price: $4.99 |
| 26 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 26 |
539110455 |
LEFT HEADLIGHT RIM GREY Price: $4.99 |
| 27 |
324-5 |
SCREW-HH Price: $0.54 |
| 27 |
539110453 |
RT HEADLIGHT LENS This part replaces 539110057. Price: $4.99 |
| 28 |
539110451 |
RT HEADLIGHT RIM GREY Price: $4.99 |
| 29 |
302-62 |
FITTING-GREASE Price: $1.34 |
| 29 |
576179401 |
HOUR METER Price: $27.99 |
| 30 |
539932956 |
GAS LINE 10" Price: $6.99 |
| 30 |
76-3090 |
LH LIFT ARM ASM Price: $637.79 |
| 31 |
505215101 |
FUEL LINE 3" Price: $2.99 |
| 31 |
99-5682 |
CARRIER BRACKET ASM This part replaces 67-1830. Price: $164.13 |
| 32 |
3219-6 |
NUT-HEX Price: $2.78 |
| 32 |
587044517 |
HOSE.3/16".VAPOR.LINE.17"LGTH This part replaces 574521302. Price: $7.99 |
| 33 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 33 |
522559101 |
SHIELD, HEAT Price: $32.99 |
| 34 |
539102733 |
CHOKE CONTROL, COMPLETE Price: $49.99 |
| 34 |
92-2377-03 |
FRONT AXLE ASM This part replaces 92-2377. Price: $4,787.10 |
| 35 |
3273-38 |
SCREW-HSH Price: $6.65 |
| 35 |
596917001 |
Screws This part replaces 539110673. Price: $2.99 |
| 36 |
596582801 |
Screws This part replaces 539990411. Price: $2.99 |
| 36 |
66-3060 |
DISCONTINUED Price: Call Us |
| 37 |
304-46 |
DRAINCOCK Price: $7.55 |
| 37 |
596584001 |
Screws This part replaces 539991034. Price: $2.99 |
| 38 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 38 |
596789701 |
Screws This part replaces 539111229. Price: $1.99 |
| 39 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 39 |
62-7650 |
GASKET Price: $4.28 |
| 40 |
595316801 |
Bolts This part replaces 539990645. Price: $3.99 |
| 40 |
92-8873 |
TANK - FUEL (DIESEL) This part replaces 63-7372. Price: $387.63 |
| 41 |
46-6560 |
BUSHING Price: $2.94 |
| 41 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 42 |
596040801 |
Hardware This part replaces 539976977. Price: $2.99 |
| 43 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 44 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 45 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 46 |
539990053 |
WASHER 1/4 INT TOOTH Price: $2.99 |
| 47 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
