| Ref | Part Number | Description |
|---|
| 1 |
21543914 |
KIT, MAIN HOUSING Price: $225.95 |
| 1 |
94-3123 |
CAPSCREW Price: $0.96 |
| 2 |
21543983 |
HSG, IZT LOWER Price: $30.60 |
| 2 |
94-3117 |
DISCONTINUED Price: Call Us |
| 3 |
21543916 |
KIT, C-SECTION Price: $224.45 |
| 3 |
94-3116 |
DISCONTINUED Price: Call Us |
| 4 |
21543998 |
SEAL, LIP 15X35X7 Price: $4.45 |
| 4 |
74-7600 |
PLUG (BALL) Price: $6.93 |
| 5 |
21543964 |
WASHER .98X1.37X.04 Price: $1.45 |
| 5 |
94-3113 |
DISCONTINUED Price: Call Us |
| 6 |
08613300 |
RING, WIRE RETAINING Price: $3.45 |
| 6 |
76-5130 |
STUD Price: $2.11 |
| 7 |
08608800 |
RING. RETAINING Price: $1.30 |
| 7 |
74-8900 |
WASHER-FLAT Price: $2.29 |
| 8 |
08613200 |
BEARING, SHAFT BALL Price: $15.80 |
| 8 |
94-3115 |
NUT Price: $1.30 |
| 9 |
74-6570 |
CUP-VALVE SPRING, LOWER Price: $3.36 |
| 10 |
08609000 |
SWASHPLATE. VARIABLE Price: $55.60 |
| 10 |
74-6560 |
SPRING-VALVE Price: $14.26 |
| 11 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 11 |
74-6550 |
CUP Price: $4.84 |
| 12 |
21543719 |
SHAFT, INPUT Price: $71.45 |
| 12 |
74-7240 |
COLLAR-SPLIT Price: $5.39 |
| 13 |
21543984 |
COVER, END IZT Price: $23.00 |
| 13 |
74-6580 |
INSERT-VALVE (1.65MM) Price: $44.94 |
| 13 |
74-6720 |
INSERT-VALVE (2.400MM) Price: $9.73 |
| 13 |
74-6980 |
INSERT-VALVE (3.050MM) Price: $9.31 |
| 14 |
08621500 |
SPRING. BLOCK Price: $1.45 |
| 14 |
74-6540 |
TAPPET-VALVE Price: $41.87 |
| 15 |
21543889 |
KIT, 10 CC BLOCK Price: $79.95 |
| 15 |
74-7570 |
LIFTING HOOK This part replaces 94-3135. Price: $9.76 |
| 16 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 17 |
74-8130 |
SCREW - HEX HD This part replaces 76-5440. Price: $1.73 |
| 18 |
74-7630 |
GASKET-COVER, VALVE Price: $30.06 |
| 19 |
74-7640 |
COVER-VALVE Price: $171.54 |
| 20 |
74-7650 |
WASHER-FLAT Price: $1.03 |
| 21 |
94-3125 |
DISCONTINUED Price: Call Us |
| 22 |
94-3124 |
SCREW-HH Price: $1.30 |
| 23 |
94-3136 |
BRACKET-LIFTING Price: $37.89 |
| 24 |
08609400 |
WASHER. THRUST .59 X .79 X .04 Price: $1.45 |
| 24 |
94-3138 |
SCREW-HH Price: $2.80 |
| 25 |
21543747 |
BRG, THRUST BALL 42X68X16 Price: $19.15 |
| 25 |
98-3840 |
BRACKET This part replaces 94-3137. Price: $9.35 |
| 26 |
21543738 |
BRG, BALL 17X40X12 Price: $16.45 |
| 26 |
94-3139 |
SCREW Price: $14.51 |
| 27 |
21543960 |
RING, RET WIRE .561 ID Price: $1.45 |
| 27 |
94-3174 |
WASHER-REPAIR Price: $10.07 |
| 28 |
74-7270 |
WASHER-FLAT Price: $3.60 |
| 29 |
74-7260 |
BOLT-HEAD Price: $17.07 |
| 30 |
08610700 |
GUIDE. SLOT Price: $3.60 |
| 30 |
94-3197 |
O-RING Price: $2.63 |
| 31 |
08610800 |
ARM. TRUNNION TAPERED SQUARE Price: $45.45 |
| 31 |
94-3196 |
DISCONTINUED Price: Call Us |
| 32 |
94-3118 |
DISCONTINUED Price: Call Us |
| 33 |
21543997 |
SEAL, LIP 12X25X7 Price: $2.25 |
| 33 |
74-7840 |
PLUG Price: $2.02 |
| 34 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 35 |
94-3198 |
SCREW-HHF Price: $2.62 |
| 36 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 37 |
94-3200 |
DISCONTINUED Price: Call Us |
| 38 |
21543918 |
KIT, BYPASS PLATE Price: $6.30 |
| 38 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 39 |
08609800 |
ACTUATOR, BYPASS Price: $28.15 |
| 39 |
94-3199 |
PIPE-BY PASS Price: $195.25 |
| 40 |
08613800 |
SEAL, LIP Price: $3.45 |
| 40 |
98-8178 |
HOSE W/OUTLET BOX This part replaces 94-3201. Price: $540.50 |
| 41 |
08611100 |
ARM. BYPASS Price: $12.95 |
| 41 |
74-7400 |
TUBE Price: $46.54 |
| 42 |
74-7840 |
PLUG Price: $2.02 |
| 43 |
21543718 |
PIN-HOLLOW .39X.5X1. Price: $3.95 |
| 43 |
94-3122 |
GASKET Price: $5.17 |
| 44 |
21543721 |
HFHCS 3/8-24X2.5 (PATCH) Price: $2.25 |
| 44 |
94-3121 |
PLUG Price: $12.11 |
| 45 |
74-7420 |
BALL Price: $1.11 |
| 46 |
21543779 |
FILTER Price: $56.45 |
| 46 |
74-7430 |
CHAMBER-TURBULENCE Price: $119.14 |
| 47 |
92-7792 |
GUIDE-VALVE (14.29 MM) Price: $25.96 |
| 48 |
74-7450 |
DISCONTINUED Price: Call Us |
| 49 |
74-7480 |
VALVE-INTAKE Price: $55.79 |
| 50 |
21543759 |
HFHCS 1/4-20X.75 Price: $1.95 |
| 50 |
92-7794 |
VALVE-EXHAUST Price: $72.59 |
| 51 |
21543754 |
GEAR, BEVEL 14T Price: $19.05 |
| 51 |
92-7795 |
SEAT-VALVE Price: $56.11 |
| 52 |
21543755 |
GEAR, BEVEL 19T Price: $25.60 |
| 52 |
92-7791 |
VALVE-SEAL, STEM Price: $9.11 |
| 53 |
21543756 |
GEAR, SPUR 53T Price: $64.50 |
| 53 |
94-8132 |
GASKET-HEAD, 1.48 Price: $239.46 |
| 54 |
21543761 |
SHAFT, MOTOR Price: $51.95 |
| 54 |
94-3120 |
BRACKET Price: $216.10 |
| 55 |
21543827 |
SHAFT, BRAKE Price: $97.40 |
| 56 |
21543757 |
AXLE, 1.0X12.3 Price: $123.95 |
| 58 |
21543816 |
SEAL, LIP 17X40X7 Price: $11.95 |
| 60 |
21543780 |
PLUG, SEAL 1.86 Price: $6.45 |
| 62 |
21543762 |
RING, RET .75 EXT Price: $1.20 |
| 63 |
21543800 |
RING, RET .440 EXT Price: $1.95 |
| 64 |
21543753 |
BRG, BALL 20X47X14 Price: $10.65 |
| 65 |
21543752 |
BRG, BALL 25X47X12 Price: $23.45 |
| 66 |
21543758 |
SEAL, LIP 25X47X7 Price: $5.95 |
| 67 |
21543741 |
RING, RET 1.56 INT Price: $6.45 |
| 68 |
21543763 |
RING, RET 1.87 INT Price: $3.45 |
| 70 |
51514300 |
KIT, LH-BRAKE ARM IZT This part replaces 00372100. Price: $47.45 |
| 73 |
21543760 |
BRAKE, PARK SPLINE Price: $11.45 |
| 81 |
21543864 |
SPACER Price: $4.95 |
| 82 |
21543865 |
SPACER Price: $19.15 |
| 100 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 110 |
07026300 |
FTG-STR .50 O-RING Price: $20.45 |
| 111 |
21543938 |
BREATHER ASSEMBLY Price: $3.95 |
| 126 |
21543828 |
RING, RET 1.43" Price: $1.55 |
| 134 |
21543905 |
KIT, SEAL Price: $49.45 |
| 136 |
02772600 |
FAN-6IN Price: $10.95 |
| 142 |
21543855 |
WASHER, .392 X 1.250 X .0 Price: $2.95 |
| 143 |
21543853 |
CAP, BRAKE Price: $2.15 |
| 208 |
21543832 |
SHCS 5/16-24X.75 Price: $2.95 |
| 209 |
21543876 |
SPRING, EXTENSION Price: $4.45 |
| 210 |
21543833 |
HOSE .5X4 Price: $5.85 |
| 216 |
21543928 |
KIT, RTN Price: $41.40 |
| 217 |
21543941 |
KIT, BREATHER Price: $20.45 |
