| Ref | Part Number | Description |
|---|
| 1 |
93-6877 |
DISCONTINUED Price: Call Us |
| 2 |
94-3634 |
DISCONTINUED Price: Call Us |
| 3 |
77-3100 |
DECAL-WARNING Price: $7.89 |
| 4 |
93-6731-03 |
SHROUD-RADIATOR, TOP This part replaces 93-6731. Price: $42.20 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 6 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 7 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
3234-4 |
SCREW-HHF Price: $0.50 |
| 9 |
83-8040 |
COVER-LEFT Price: $247.94 |
| 10 |
93-6730-03 |
SHROUD-RADIATOR, BOTTOM This part replaces 93-6730. Price: $36.31 |
| 11 |
110-3257 |
HOSE-FUEL This part replaces 71-3382. Price: $17.26 |
| 12 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 13 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 14 |
83-9030 |
FOAM-TOP Price: $5.26 |
| 15 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 16 |
32128-44 |
NUT Price: $2.69 |
| 17 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 18 |
3234-28 |
SCREW-HHF Price: $1.59 |
| 19 |
83-7980 |
DISCONTINUED Price: Call Us |
| 20 |
32148-8 |
NUT-CLINCH Price: $2.31 |
| 22 |
323-6 |
SCREW-HH Price: $0.66 |
| 23 |
83-8150-03 |
SCREEN ASM This part replaces 83-8150. Price: $354.15 |
| 24 |
83-8070-03 |
SHIELD-RADIATOR, BOTTOM This part replaces 83-8070. Price: $29.88 |
| 25 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 26 |
83-8210-03 |
PANEL-FRONT, LEFT This part replaces 83-8210. Price: $85.69 |
| 27 |
93-6932 |
COOLER-OIL Price: $466.61 |
| 28 |
83-7970 |
CONNECTOR Price: $58.21 |
| 29 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 30 |
88-6730-03 |
BRACKET-SCREEN, FRONT This part replaces 88-6730. Price: $35.76 |
| 31 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 32 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 33 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 34 |
93-6803 |
FITTING-90 DEG Price: $35.80 |
| 35 |
73-4740 |
HANDLE KNOB This part replaces 93-7159. Price: $8.09 |
| 36 |
93-6804 |
HOSE Price: $54.29 |
| 37 |
88-6720-03 |
DISCONTINUED This part replaces 88-6720. Price: Call Us |
| 38 |
93-6726 |
DISCONTINUED Price: Call Us |
| 39 |
93-6805 |
HOSE Price: $23.30 |
| 40 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 41 |
2412-41 |
CLAMP-R Price: $4.82 |
| 42 |
93-2191 |
AIR CLEANER MOUNTING BAND ASM Price: $54.37 |
| 43 |
93-2190 |
AIR CLEANER ASM Price: $217.17 |
| 45 |
2412-92 |
CLAMP-HOSE Price: $2.44 |
| 46 |
93-6933 |
SLEEVE-PROTECTIVE Price: $36.66 |
| 47 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 48 |
32128-33 |
NUT-HF Price: $0.25 |
| 50 |
93-6876 |
HOSE-AIR INTAKE, UPPER Price: $18.80 |
| 51 |
93-6724 |
HOSE-INTAKE Price: $42.95 |
| 52 |
93-6728 |
HOSE-RADIATOR, TOP Price: $43.77 |
| 53 |
93-6729 |
HOSE-RADIATOR, LOWER Price: $54.09 |
| 54 |
237-30 |
O-RING Price: $2.50 |
| 55 |
117-3276 |
DECAL-DANGER This part replaces 93-7840. Price: $10.70 |
| 56 |
94-3665-03 |
GUARD ASM This part replaces 94-3665. Price: $47.45 |
| 57 |
32148-6 |
NUT-CLINCH Price: $1.24 |
| 501622101 |
501622101 |
SEAL COLLAR Price: $3.84 |
| 501628601 |
501628601 |
Price: $4.80 |
| 501792501 |
501792501 |
Price: $4.33 |
| 501796402 |
501796402 |
CHOKE CONTROL Price: $7.99 |
| 501835802 |
501835802 |
THROTTLE ROD Price: $27.99 |
| 501862020 |
501862020 |
Price: Call Us |
| 501862102 |
501862102 |
GASKET Price: $4.99 |
| 501862502 |
501862502 |
GASKET Price: $4.99 |
| 503151903 |
503151903 |
AIR FILTER Price: $19.99 |
| 503151905 |
503151905 |
AIR FILTER Price: $22.99 |
| 503151906 |
503151906 |
AIR FILTER Price: $22.99 |
| 503152202 |
503152202 |
FILTER HOLDER Price: $11.99 |
| 503203219 |
503203219 |
SCREW Price: $3.99 |
| 503281019 |
503281019 |
CARBURETOR CPL HDA-98 WALBRO Price: $199.99 |
| 503496903 |
503496903 |
SCREW Price: $5.99 |
| 734114601 |
819070816 |
Washer 7/32 x 1/2 x 16 Gauge This part replaces 734114601. Price: $5.99 |
