| Ref | Part Number | Description |
|---|
| 1 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 1 |
545125301 |
ASSY-CABLE WIRE HARNESS This part replaces 530150561. Price: $19.99 |
| 2 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 2 |
545066001 |
TRIGGER THROTTLE This part replaces 530059807. Price: $5.99 |
| 3 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 3 |
530057855 |
THROTTLE HSG RH Price: $11.99 |
| 4 |
530016448 |
SCREW Price: $2.99 |
| 5 |
530016449 |
SCREW M4 X 1.75 PT 16MM Price: $3.99 |
| 5 |
67-8510 |
V-BELT, FAN Price: $28.48 |
| 6 |
530016454 |
SPRING TRIGGER Price: $4.99 |
| 6 |
67-8390 |
SPACER-FAN Price: $63.55 |
| 7 |
530059804 |
THROTTLE LOCKOUT Price: $4.99 |
| 7 |
67-8380 |
DISCONTINUED Price: Call Us |
| 8 |
32128-33 |
NUT-HF Price: $0.25 |
| 8 |
545045601 |
SPRING LOCKOUT Price: $4.99 |
| 9 |
21-5640 |
JOINT-BALL Price: $27.80 |
| 9 |
530057856 |
THROTTLE HSG LH Price: $11.99 |
| 10 |
3219-14 |
NUT-HEX Price: $0.25 |
| 10 |
545049301 |
KIT SWITCH This part replaces 545030601. Price: $8.99 |
| 11 |
25-8640 |
SCREW-HH Price: $1.09 |
| 11 |
530015820 |
BOLT, TYPE 2 Price: $3.99 |
| 12 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 12 |
530150076 |
HANDLE ASSIST Price: $9.99 |
| 13 |
43-3780 |
SWIVEL-CABLE Price: $25.86 |
| 14 |
530059185 |
CLAMP ASSIST HANDLE Price: $2.99 |
| 14 |
67-8360 |
DISCONTINUED Price: Call Us |
| 15 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 15 |
530091373 |
NUT-"D" HANDLE This part replaces 530016152. Price: $3.99 |
| 16 |
530016344 |
SCREW Price: $2.99 |
| 16 |
67-8250 |
ROD-THROTTLE Price: $50.29 |
| 17 |
3253-12 |
WASHER-LOCK/SP Price: $0.25 |
| 17 |
530096218 |
FLEX-LOWER Price: $6.99 |
| 18 |
321-4 |
SCREW-HH Price: $0.99 |
| 18 |
545081006 |
HSG DRIVESHAFT LOWER This part replaces 545008705. Price: $24.99 |
| 19 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 20 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 20 |
530052286 |
Limiter-Line Price: $0.68 |
| 21 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 21 |
530015814 |
SCREW Price: $0.17 |
| 22 |
3217-5 |
NUT-HEX Price: $0.25 |
| 22 |
530016014 |
SCREW - CARB. ADAPTOR Price: $2.99 |
| 23 |
530016301 |
SCREW Price: $2.99 |
| 23 |
67-8240-03 |
BRACKET-CONTROL, THROTTLE This part replaces 67-8240. Price: $27.40 |
| 24 |
321-6 |
SCREW-HH Price: $0.25 |
| 24 |
530015771 |
SCREW 1/4-20 X 7/8 (TAP Price: $3.99 |
| 25 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 25 |
530057554 |
BRACKET SHIELD STRAIGHT SHAFT Price: $4.99 |
| 26 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 26 |
530096295 |
ASSY GEARBOX Price: $34.99 |
| 27 |
530150294 |
ASSY DUST CUP Price: $11.99 |
| 27 |
67-8920-03 |
SHIELD-HEAT This part replaces 67-8920. Price: $16.56 |
| 28 |
321-39 |
SCREW-HH Price: $0.42 |
| 28 |
537338310 |
TRIMMER HEAD T25 This part replaces 537338302. Price: $27.99 |
| 29 |
70-2040 |
TRIM Price: $3.35 |
| 30 |
67-9150-03 |
SUPPORT-GOVERNOR ASM This part replaces 67-9150. Price: $65.91 |
| 31 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 32 |
33114-020 |
SCREW-HH Price: $0.28 |
| 33 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 34 |
33115-020 |
SCREW-HH Price: $0.88 |
| 35 |
3254-20 |
WASHER-LOCK, INT This part replaces 3254-3. Price: $1.29 |
