| Ref | Part Number | Description |
|---|
| 1 |
136-2941 |
KIT-SERVICE, PLANETARY ASM This part replaces 136-2913. Price: $3,119.29 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
237-166 |
O-RING Price: $10.46 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532175131. Price: $59.99 |
| 3 |
100-3046 |
SHAFT-BRAKE, SPLINED Price: $192.79 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
100-3069 |
RH BRAKE ASM Price: $802.37 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
100-3070 |
LH BRAKE ASM Price: $802.37 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
33106-030 |
SCREW-HHF Price: $1.15 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
33106-080 |
SCREW-HHF Price: $2.80 |
| 7 |
819272016 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
93-7972 |
RING-RETAINING, INTERNAL Price: $0.25 |
| 9 |
133-2744 |
TIRE AND WHEEL ASM Price: $500.73 |
| 9 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 10 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 11 |
93-6498 |
FENDER-REAR Price: $312.87 |
| 12 |
93-6528-03 |
STRAP-MOUNT, FENDER Price: $37.52 |
| 13 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 15 |
94-7127 |
SPLASH GUARD ASM Price: $161.83 |
| 16 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 17 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 18 |
132-5631 |
HYD MOTOR ASM Price: $2,248.91 |
| 19 |
136-2373 |
MOTOR-HYDRAULIC (W/SPEED SENSOR) Price: $2,746.75 |
| 20 |
93-7984 |
GASKET Price: $20.21 |
| 21 |
33116-110 |
SCREW-HH Price: $1.97 |
| 22 |
119-4854 |
FITTING-STR Price: $54.99 |
| 23 |
340-104 |
FITTING-HYD, TEE Price: $74.38 |
| 24 |
104-3795 |
FITTING-TEE Price: $142.37 |
| 25 |
340-91 |
FITTING-STR Price: $36.83 |
| 26 |
117-0674 |
TUBE-TRACTION Price: $175.24 |
| 26 |
532126847 |
BUSHING.DRAGLINK (2 2) Price: $4.99 |
| 27 |
33096-00 |
WASHER-FLAT Price: $1.76 |
| 28 |
131-9634 |
HYDRAULIC HOSE ASM Price: $102.64 |
| 28 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 29 |
120-8563 |
HOSE ASM Price: $325.02 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
120-8564 |
HOSE ASM Price: $412.35 |
| 30 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 31 |
119-0582 |
HOSE ASM Price: $96.66 |
| 32 |
136-2308-03 |
SUPPORT-MOUNT, DRAIN Price: $33.80 |
| 32 |
532192757 |
ROD.TIE.WIRE.FORM Price: $29.99 |
| 33 |
136-2339 |
HARNESS-WIRE, ADAPTOR Price: $49.61 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 47 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
874780564 |
BOLT Price: $4.99 |
