| Ref | Part Number | Description |
|---|
| 1 |
33108-025 |
Screw-HHF Price: Call Us |
| 1 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 2 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 2 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 3 |
3290-271 |
RIVET-POP Price: $0.25 |
| 3 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 4 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 4 |
532008156 |
FOOT PEDAL COVER Price: $2.64 |
| 5 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 5 |
93-4215 |
DISCONTINUED Price: Call Us |
| 6 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 6 |
92-7424 |
HOSE-OVERFLOW, RADIATOR Price: $17.86 |
| 7 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 7 |
819131016 |
WASHER Price: $2.99 |
| 8 |
32128-20 |
NUT-HF Price: $0.99 |
| 8 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 9 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 9 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 10 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 10 |
92-7374 |
SHROUD-FAN, RH Price: $98.41 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 11 |
93-7584 |
HOSE-INTAKE Price: $92.76 |
| 12 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 12 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY Price: $21.38 |
| 13 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 13 |
93-7553 |
SEAL-HOOD Price: $41.30 |
| 14 |
32148-10 |
NUT-CLINCH Price: $1.29 |
| 14 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 15 |
532133332 |
ARM, BRAKE ASMBLY Price: $6.71 |
| 15 |
76-8750 |
PLATE-WARNING Price: $9.67 |
| 15 |
94-4577 |
DECAL - WARNING, FAN, JAP Price: $22.92 |
| 16 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 16 |
819251816 |
WASHER T Price: $4.99 |
| 17 |
304-46 |
DRAINCOCK Price: $7.55 |
| 17 |
812000034 |
Ring, Klip Price: $2.99 |
| 18 |
532151332 |
SPRING, BRAKE ROD Price: $4.99 |
| 18 |
92-7463 |
DISCONTINUED Price: Call Us |
| 19 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 19 |
92-7516-03 |
BRACKET-SUPPORT, COOLER BASE This part replaces 92-7516. Price: $46.80 |
| 20 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 20 |
74-3410 |
RADIATOR ASM Price: $2,099.35 |
| 21 |
114-3995 |
OIL COOLER ASM This part replaces 82-3740. Price: $1,388.56 |
| 21 |
532131461 |
CLUTCH KIT This part replaces 532131460. Price: $13.99 |
| 22 |
532144585 |
TRUNNION, LEFT Price: $8.99 |
| 22 |
92-7631 |
SEAL-SCREEN Price: $33.08 |
| 23 |
94-2638 |
NUT-FLAT Price: $0.54 |
| 24 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 24 |
92-7505-03 |
SCREEN ASM This part replaces 92-7505. Price: $1,733.53 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 25 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 26 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 26 |
93-6028 |
PLATE-LOGO Price: $13.70 |
| 27 |
532127369 |
LINK.MOWER.REAR Price: $9.99 |
| 27 |
93-4208 |
SEAL-SCREEN, STRIP Price: $68.49 |
| 28 |
32151-72 |
RING-RETAINING Price: $1.59 |
| 28 |
532140776 |
REAR MOWER LIFT ASSY Price: $40.26 |
| 29 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 29 |
92-7535 |
HOSE ASM Price: $197.33 |
| 30 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 30 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 31 |
237-65 |
O-RING Price: $2.50 |
| 31 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 32 |
37-8771 |
BOLT-SHOULDER,HFH Price: $3.59 |
| 33 |
92-7388-03 |
SUPPORT-RADIATOR ASM This part replaces 92-7388. Price: $365.32 |
| 34 |
69-3020 |
LATCH-CAMLOC Price: $43.54 |
| 35 |
3269-4 |
RIVET-POP Price: $1.19 |
| 36 |
92-7623-03 |
DISCONTINUED This part replaces 92-7623. Price: Call Us |
| 37 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 38 |
2410-42 |
CAP-END Price: $11.62 |
| 39 |
92-7493 |
DISCONTINUED Price: Call Us |
| 40 |
92-7558 |
DISCONTINUED Price: Call Us |
| 41 |
92-7416-03 |
STRAP-RADIATOR This part replaces 92-7416. Price: $32.23 |
| 42 |
92-7375 |
DISCONTINUED Price: Call Us |
| 43 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 44 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 45 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 46 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 47 |
94-2646 |
FAN GUARD WA *B Price: $362.62 |
| 48 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 49 |
2412-96 |
CLAMP-R Price: $3.46 |
| 50 |
2410-64 |
PLUG-BUTTON Price: $0.74 |
| 51 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 52 |
94-8105 |
CLAMP-TUBE Price: $3.17 |
