| Ref | Part Number | Description |
|---|
| 1 |
120-8589-03 |
BRACKET-TUBE Price: $60.38 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 2 |
120-0608-03 |
HINGE Price: $130.93 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
120-0611-03 |
STRAP Price: $70.31 |
| 4 |
120-0613-03 |
STRAP Price: $81.86 |
| 5 |
120-0757-03 |
BRACKET-TUBE Price: $29.00 |
| 6 |
120-0799-03 |
STRAP Price: $92.15 |
| 7 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $11.99 |
| 9 |
117-8114 |
SENSOR-SONIC Price: $850.04 |
| 10 |
120-0647 |
NUT Price: $21.97 |
| 11 |
120-0648 |
PLUG-PROGRAMMING Price: $62.08 |
| 12 |
120-0646 |
HOUSING-LOWER, ULTRASONIC SENSOR Price: $89.58 |
| 13 |
120-0645 |
COVER-SENSOR, ULTRASONIC Price: $80.27 |
| 14 |
120-0772 |
CAP-TUBE Price: $5.21 |
| 15 |
92-0010 |
U-BOLT Price: $10.65 |
| 16 |
104-7201 |
NUT-HF Price: $0.69 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 17 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 18 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 19 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 20 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
322-20 |
SCREW-HH Price: $1.79 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $29.99 |
| 22 |
3234-36 |
SCREW-HHF Price: $0.75 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 23 |
120-0761 |
BUSHING Price: $3.39 |
| 25 |
532412894 |
CABLE.STARTER.6GA.BL/RED.14. Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $19.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 33 |
532411933 |
KEY.CHAIN.BLISTER.PACK.GEN.USA Price: $6.99 |
| 34 |
532110712 |
SWITCH LT Price: $4.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $74.99 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 55 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $24.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $11.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $11.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532400725. Price: $2.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
532192540 |
SCREW.PLASTITE Price: $2.99 |
