| Ref | Part Number | Description |
|---|
| 1 |
532199298 |
DECK.SVC.54".5GWB.GREY This part replaces 532403125. Price: $449.99 |
| 1 |
94-9141-01 |
SCREEN Price: $546.46 |
| 2 |
119-8016 |
TOP PANEL ASM This part replaces 94-9135-01. Price: $1,587.76 |
| 3 |
119-6051 |
PANEL-HOPPER, LH This part replaces 94-9129-01. Price: $1,356.99 |
| 5 |
94-9128-01 |
PANEL-FRONT Price: $168.03 |
| 6 |
13-6760 |
DECAL-CAUTION Price: $41.90 |
| 6 |
532196066 |
COVER.MANDREL.LH.54"20 Price: $22.99 |
| 7 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 7 |
532197181 |
COVER.MANDREL.RH.54.20 Price: $27.99 |
| 8 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 9 |
32128-32 |
NUT-HHF Price: $2.69 |
| 10 |
13-2930 |
DISCONTINUED Price: Call Us |
| 11 |
119-6242 |
PIN-HINGE This part replaces 283-39. Price: $27.18 |
| 12 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 13 |
93-4003-01 |
TAILGATE ASM Price: $3,420.04 |
| 14 |
13-7430 |
DECAL-WARNING Price: $67.40 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
3229-7 |
SCREW-CARR Price: $0.87 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
13-7340-01 |
STIFFENER-LH Price: $300.82 |
| 16 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 18 |
93-4031-01 |
STRAP-HOPPER, TOP Price: $74.75 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 19 |
93-4042-01 |
SUPPORT-HOPPER Price: $310.58 |
| 20 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 21 |
12-8810 |
SPRING-EXTENSION Price: $26.98 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
32122-42 |
SCREW Price: $1.69 |
| 23 |
94-9139-01 |
PANEL-BOTTOM, LH Price: $489.00 |
| 24 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
13-3710 |
WASHER Price: $3.05 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
325-6 |
SCREW-HH Price: $1.42 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $64.99 |
| 28 |
94-9138-01 |
PANEL-BOTTOM, CENTER Price: $244.33 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
94-9137-01 |
PANEL-BOTTOM, RH Price: $489.00 |
| 30 |
3250-32 |
SCREW-PPH Price: $0.54 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
93-4030-01 |
STRAP-HOPPER, FRONT Price: $22.13 |
| 32 |
3274-54 |
SCREW-HSH Price: $1.41 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 33 |
93-0184 |
DECAL-HOPPER Price: $41.42 |
| 34 |
106-9665 |
TUBE & CAP ASM This part replaces 65-5871. Price: $17.71 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 35 |
65-5890 |
CAP-END Price: $8.09 |
| 36 |
2412-102 |
CLAMP-R Price: $6.85 |
| 37 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 38 |
323-6 |
SCREW-HH Price: $0.66 |
| 39 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 40 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 41 |
325-7 |
SCREW-HH Price: $1.53 |
| 42 |
93-7708 |
STRIP-SEAL Price: $10.93 |
| 43 |
120-6199 |
HOPPER ASM This part replaces 92-2409. Price: $8,949.33 |
| 43 |
531169301 |
SERVICE KIT ARM.IDLER This part replaces 532196065. Price: $9.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $54.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 58 |
531168601 |
SERVICE KIT BAFFLE.RIGHT.54" This part replaces 532187342. Price: $12.99 |
| 59 |
531168701 |
SERVICE KIT BAFFLE.LEFT.54" BA This part replaces 532187344. Price: $19.99 |
| 60 |
531168801 |
SERVICE KIT BAFFLE BAFFLE CENT This part replaces 532187607. Price: $19.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $17.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 120 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 188 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X This part replaces 872140716. Price: $9.99 |
| 196 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
