| Ref | Part Number | Description |
|---|
| 1 |
B193230GS |
KIT, Cradle, Gen (Includes Items 20, 31, 55, 87 & 88) Price: $429.99 |
| 2 |
38353GS |
MOUNT, Vibration Price: $26.39 |
| 3 |
56893GS |
CRIMPTITE, 10-24 x 1/2 Price: $1.95 |
| 4 |
190220GS |
ADAPTER, Engine Price: $40.82 |
| 5 |
~NSP |
ASSY., Alternator (see page 4) Price: Call Us |
| 7 |
62265GS |
GROMMET Price: $6.69 |
| 8 |
96796GS |
WASHER, 8.4 x 22.2 x 3 Price: $2.79 |
| 9 |
194208GS |
KIT, Alt to Heat Shield Hardware Price: $16.59 |
| 10 |
190274BGS |
SBHCS, 3/8-16 x 1" Price: $3.41 |
| 11 |
25254GS |
HHCS 5/16-24 x 9-7/8 Price: $9.20 |
| 12 |
189302BGS |
WIRE, #16, Red Price: $15.70 |
| 16 |
B77304GS |
SUPPORT, Engine Price: $22.49 |
| 17 |
2828635SM |
SCREW-HEX WSHR HD TAP This part replaces 75246GS. Price: $4.26 |
| 18 |
195404GS |
ASSY, Stepper Motor Price: $119.99 |
| 19 |
J93074GS |
SUPPORT, Heat shield Price: $109.99 |
| 20 |
B4986GS |
DECAL, Ground Price: $2.75 |
| 21 |
194155GS |
KIT, Vibration Mount Price: $13.90 |
| 22 |
86494GS |
SCREW, Wing M6 - 1.0 x 16 Price: $2.51 |
| 24 |
194950GS |
ASSY., Heatshield Price: $39.90 |
| 25 |
191190GS |
CAP Price: $3.09 |
| 26 |
74908GS |
TAPTITE, M5 - 0.8 x 10 Price: $2.69 |
| 30 |
194543GS |
KIT, Throttle Linkage Hardware Price: $20.49 |
| 31 |
200310GS |
DECAL, Warning Exhaust Price: $14.83 |
| 34 |
195422GS |
COVER, RBC Plastic w/ Cap Price: $12.35 |
| 35 |
791745 |
LINE, Fuel Price: $8.97 |
| 37 |
B2153GS |
SCREW, Self Driller, 12-14 x 7/8 Price: $3.95 |
| 38 |
192376GS |
SCREW, 12 - 24 x 1/2 Thread Forming Price: $2.89 |
| 39 |
704130 |
SCREW, HEX, 1/4-20X.5 This part replaces B4300GS. Price: $3.28 |
| 40 |
197955GS |
SCREW, M8 - 1.25 x 20, Taptite Price: $2.94 |
| 41 |
310574GS |
VALVE, Fuel This part replaces 193272GS. Price: $9.40 |
| 43 |
B4769GS |
CONTACTOR, Starter Price: $23.25 |
| 44 |
196035GS |
ASSY., Tank Fuel (Includes Items 41, 51, 52, 56 & 65) Price: $176.80 |
| 45 |
189135GS |
CAP, Tank Fuel Price: $17.23 |
| 46 |
B4135GS |
PIN, Handle Release Price: $6.09 |
| 47 |
77395GS |
LOCKNUT, M6 Price: $3.09 |
| 48 |
195373GS |
WIRE, Ground Price: $1.85 |
| 49 |
95920GS |
LINKAGE, Stepper Motor to Bell Crank Price: $13.26 |
| 51 |
94480GS |
DECAL, Operating Instructions Price: $14.83 |
| 52 |
194984GS |
DECAL, Warning Price: $13.99 |
| 53 |
194034GS |
KIT, Fold-down Handle Hardware Price: $9.51 |
| 54 |
95349GS |
PLATE, Adjust Price: $5.79 |
| 55 |
197797GS |
DECAL, Fuel Shutoff Price: $7.41 |
| 56 |
202997GS |
DECAL, Warning, CO Price: $12.80 |
| 57 |
310574GS |
VALVE, Fuel This part replaces 189759GS. Price: $9.40 |
| 58 |
202526GS |
ASSY. Control Panel Price: $586.05 |
| 60 |
J193512GS |
SUPPORT, Tray Battery Price: $67.25 |
| 61 |
95348GS |
BRACKET, Bell Crank Price: $6.39 |
| 62 |
95921GS |
LINKAGE, Bell Crank to Throttle Price: $9.70 |
| 63 |
96717GS |
SPRING Price: $49.81 |
| 65 |
192724GS |
GAUGE, Gas Price: $6.70 |
| 68 |
J195680GS |
TRAY, Battery Price: $57.99 |
| 69 |
193043GS |
BATTERY Price: $127.58 |
| 74 |
193347GS |
KIT, Hardware Battery Price: $2.49 |
| 76 |
185939GGS |
WIRE, #55 Black Price: $8.70 |
| 78 |
189302EGS |
WIRE, #13 Red Price: $10.85 |
| 83 |
192403YGS |
WIRE, 18 AWG, Red, 3.5" Price: Call Us |
| 85 |
B193200GS |
ASSY, Fold Down Handle Price: $34.76 |
| 86 |
198669GS |
GRIP, Handle Price: $7.69 |
| 87 |
195459GS |
DECAL, Neutral Ground Price: $3.45 |
| 88 |
195940GS |
DECAL, Ground, French Price: $2.70 |
